- Page 1 Owner’s Manual Bedienungsanleitung Mode d’emploi Manual de instrucciones Manual do Proprietário Manuale di istruzioni Руководство пользователя...
-
Page 2: Important Safety Instructions
Explanation of Graphical Symbols The lightning flash with arrowhead symbol CAUTION within an equilateral triangle is intended to alert the user to the presence of uninsulated RISK OF ELECTRIC SHOCK “dangerous voltage” within the product’s DO NOT OPEN enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. - Page 3 Yamaha Corporation of America or its subsidiaries. of other electronic devices. Compliance with FCC regulations does * This applies only to products distributed by YAMAHA CORPORATION OF AMERICA. (class B) COMPLIANCE INFORMATION STATEMENT...
- Page 4 Owner’s Manual...
-
Page 5: Table Of Contents
Head Amplifier Parameters That Can be Monitored and Controlled ......16 Troubleshooting ......17 Troubleshooting ..........17 Messages ............18 Specifications....... 135 General Specifications ........135 Analog Input Characteristics (Ri8-D only) ..136 Analog Output Characteristics (Ro8-D only)...136 Digital I/O Characteristics ......136 Dimensions ............137 Owner’s Manual... -
Page 6: Precautions
• Do not block the vents. This device has ventilation holes at the rear to prevent the included power cord may not be compatible. Please check with your Yamaha the internal temperature from becoming too high. In particular, do not place the dealer. - Page 7 Yamaha cannot be held responsible for damage caused by improper use or Information for Users on Collection and Disposal of Old modifications to the device, or data that is lost or destroyed. Equipment This symbol on the products, packaging, and/or...
-
Page 8: Introduction
1U chassis requirements to avoid heat buildup: The Ri8-D is dedicated for input rack and the Ro8-D is for • When mounting the unit in a rack with devices such output. This enables an installation of rack for an occasion as power amplifiers that generate a significant requires input only or output only. -
Page 9: About Dante
(in theory) of audio over a GbE network. (The Ri8-D features 8 in with a 24/32-bit resolution. The Ro8-D features 8 out with a 24/32-bit resolution.) • Dante-enabled devices will automatically configure their network interfaces and find each other on the network. -
Page 10: Controls And Functions
Ri8-D/Ro8-D. The UNIT ID must be a unique from a compatible digital mixing console or computer number in the network so that the Ri8-D/Ro8-D will application. No phantom power will be supplied, be able to transmit and receive audio signals over a... - Page 11 0 to F (0 to 15) or from 10 to 1F (16 to such as CL Series or a non-Ri8-D-native device such 31). as M7CL Series. Information on which devices feature Ri8-D-native support is available at the Yamaha pro Switch Setting Description...
- Page 12 (i.e., settings used prior to the most recent power-off). If you plan to connect an Ri8-D/Ro8-D-native device, such as a CL series product, set the switches to [REFRESH]. The Ri8-D/Ro8-D will not input or...
-
Page 13: Rear Panel
[PRIMARY]/[SECONDARY] Connectors The Ri8-D/Ro8-D can be connected to other Dante-compatible devices (such as a CL-series product) via these RJ45 connectors using standard Ethernet cables (CAT5e or better recommended). -
Page 14: About Connections
Star Network In a star network, each device is connected to a central network switch. Using a GbE-compatible network switch There are two ways to connect the Ri8-D/Ro8-D to a Dante enables you to configure a wide-band, large-scale network. network. -
Page 15: About Dante Controller
Dante networks. Use this application if you plan to connect or set up Dante-enabled devices that do not feature Ri8-D/Ro8-D-native support. Please download the latest Dante Controller from the following website. Please note that Dante Controller Version 3.2.1 or later supports Ri8-D/Ro8-D. -
Page 16: Head Amp Control
ID (as AD8HR Device ID). The Ri8-D head amplifiers can be remotely controlled If you combine Rio3224-D or Rio1608-D or add an from a host device, such as a compatible Yamaha digital AD8HR or SB168-ES in the network, make sure that the mixing console. -
Page 17: Troubleshooting
The cables are not connected properly. Connect the cables properly. The DIP switches are set to REFRESH, but the Start the Ro8-D-native device to send the set- Ro8-D-native device has not started up. ting to the Ro8-D. Output is muted. -
Page 18: Messages
In that case, repair is required. Contact your Yamaha dealer. Flash x3 DAISY CHAIN setting has been selected, or SYSTEM... -
Page 19: Specifications
–20 - 60°C Included Accessories Owner’s Manual, Power Cord INPUT to OUTPUT means Ri8-D INPUT to Ro8-D OUTPUT Total Harmonic Distortion is measured with 18dB/octave filter @80kHz Hum & Noise are measured with A-Weight filter. Crosstalk is measured with a 30dB/octave filter @22kHz... -
Page 20: Analog Input Characteristics (Ri8-D Only)
* In these specifications, 0dBu = 0.775 Vrms. * All input AD converters are 24bit linear, 128times oversampling. * +48V DC ( phantom power ) is supplied to INPUT XLR type connectors via each individual software controlled switch. Analog Output Characteristics (Ro8-D only) Output Level Max.Output Level... -
Page 21: Dimensions
Dimensions Dimensions Ri8-D Ro8-D Unit: mm Owner’s Manual... - Page 23 Niederlassung und bei Yamaha Vertragshändlern in den jeweiligen Bestimmungsländern erhältlich. Pour plus de détails sur les produits, veuillez-vous adresser à Yamaha ou au distributeur le plus proche de vous figurant dans la liste suivante. Para detalles sobre productos, contacte su tienda Yamaha más cercana o el distribuidor autorizado que se lista debajo.
