15.2 Burner and nozzle characteristics table

Rated heating
Burner capacity (kW)
Auxiliary 1.05
Semi rapid
Rapid
Ultra-rapid
Rated heating
Burner
capacity (kW)
Auxiliary 1.05
Semi rapid
Rapid
Ultra-rapid

15.3 Arrangement of the burners on the hob

42
Instructions for the installer
Nozzle diameter
1/100 mm
50
1.8 65
3.0 85
3.9 100
Nozzle diameter
1.8
3.0
3.9
LPG – G30/G31 28/37 mbar
Reduced flowrate
(W)
400
500
800
1600
NATURAL GAS – G20 20 mbar
1/100 mm
72 (X)
97 (Z)
115 (Y)
135 (K)
Flowrate
g/h G30
76
131
218
284
Reduced flowrate
(W)
400
500
800
1600
BURNERS min. and max. Ø (in
1. Auxiliary
2. Semi-rapid
3. Rapid
4. Ultra-rapid
Flowrate
g/h G31
75
129
214
279
cm)
12 - 14
16 - 24
18 - 26
18 - 26
