Sloan SF Series Installation Instructions Manual

INSTALLATION INSTRUCTIONS FOR SLOAN SF SERIES
ELECTRONIC SENSOR ACTIVATED LAVATORY FAUCETS
SF-2100 Series
Adapter Powered with Battery Backup,
Sensor Activated, Pedestal Style Lavatory Faucets
SF-2150 Series
Battery Powered, Sensor Activated,
Pedestal Style Lavatory Faucets
SF-2200 Series
Adapter Powered with Battery Backup
Sensor Activated, Gooseneck Style
Lavatory Faucets
SF-2250 Series
Battery Powered, Sensor Activated
Gooseneck Style Lavatory Faucets
Sloan Valve Company warrants its SF Series Electronic Hand Washing Faucets to be made of first class materials, free from defects of material or workmanship under normal use and
to perform the service for which they are intended in a thoroughly reliable and efficient manner when properly installed and serviced, for a period of one year from date of purchase.
During this period, Sloan Valve Company will, at its option, repair or replace any part or parts which prove to be thus defective if returned to Sloan Valve Company, at customer's cost,
and this shall be the sole remedy available under this warranty. No claims will be allowed for labor, transportation or other incidental costs. This warranty extends only to persons or
organizations who purchase Sloan Valve Company's products directly from Sloan Valve Company for purpose of resale. This warranty does not cover the life of the batteries.
THERE ARE NO WARRANTIES WHICH EXTEND BEYOND THE DESCRIPTION ON THE FACE HEREOF. IN NO EVENT IS SLOAN VALVE COMPANY
RESPONSIBLE FOR ANY CONSEQUENTIAL DAMAGES OF ANY MEASURE WHATSOEVER.

PRIOR TO INSTALLATION

Prior to installing the Sloan SF Series Electronic Lavatory Faucet, install
the items listed below. Also, refer to the appropriate rough-in diagram.
• Plug-In Adapter
Models SF-2100/SF-2200/SF-2300/SF-2400 only — Install
electrical receptacle(s) for plug-in adapter(s) — 120 VAC, 1 amp
service for each 6 VDC plug-in adapter used.
International models may be supplied with a 220 VAC/VDC
transformer.
• Hot and cold water supply lines or tempered water supply line
• Drain lines

TOOLS REQUIRED FOR INSTALLATION

• Electric drill for drilling anchor holes (1/4" or 6 mm drill bit)
• Straight blade and phillips blade screwdrivers
• Open end wrenches (9, 11, 13, 16, 22 mm)
The components supplied with International Models of the SF Series Faucets may vary from what is shown in this manual. Consult factory to identify
variations that may apply to your market.
SF-2300 Series
Adapter Powered with Battery Backup
Sensor Activated, 4" Centerset Lavatory Faucets
SF-2350 Series
Battery Powered, Sensor Activated
4" Centerset Lavatory Faucets
SF-2400 Series
Adapter Powered with Battery Backup,
Sensor Activated, Pedestal Style Lavatory
Faucets
SF-2450 Series
Battery Powered, Sensor Activated,
Pedestal Style Lavatory Faucets

LIMITED WARRANTY

Important:
• INSTALL ALL ELECTRICAL WIRING IN ACCORDANCE WITH
NATIONAL/LOCAL CODES AND REGULATIONS.
• INSTALL ALL PLUMBING IN ACCORDANCE WITH APPLICABLE CODES
AND REGULATIONS.
• A 6 VDC STEP-DOWN ADAPTER MUST BE USED FOR HARDWIRE
APPLICATIONS.
• BEFORE CONNECTING COPPER TUBE(S) OR FLEX HOSE(S) TO
SUPPLY STOP(S), FLUSH ALL WATER LINES UNTIL WATER IS CLEAR.
Code No. 0816496
Rev. 4 (04/14)
