5.4.1
IP Assignment
Static IP Assignment refers to the fixed settings of the ISP or network engineering
department.
IP Address: Includes Static, DHCP and PPPoE. DHCP and PPPoE are typically dynamic
IPs where a DHCP server or your ISP designates an IP address each time you log on.
When using the " Static" setting, you must enter the following information:
- IP Address The IP address of the IP CAM
- Subnet Mask Set by default to 255.255.255.0
- Gateway Default gateway
When using the " DHCP" setting, you do not need to enter any of the above settings. You
must only enter the address of the DHCP Server in the " Server" field.
When using the " PPPoE" setting, you must correctly enter your ISP Login name and
password. Please refer to unit 5.4.2 for details.
5.4.2 PPPoE
This menu allows you to enter the dial-up settings during PPPoE IP assignment. This
usually refers to entering your ID account name and password. Remember that you must
also enter your ISP log-in settings.
How to Setup PPPoE
Step 1. Enter your correct user ID in the " Account" field.
Step 2. Enter your correct password in the " Password" field.
Step 3. Click on
Note: Because PPPoE utilizes a dynamic IP address from an ISP, the IP settings for the
DN-16023 could differ for each use. It is suggested that an IP Router be used to
connect to the PPPoE or DDNS. This will assist your computer in finding the
IPCAM.
5.4.3
HTTP Server
This menu allows you to enter the port number of the DN-16023 IPCAM internal web
server (or HTTP Server) via HTTP protocol. The default port number is " 80" .
IP CAM USER' S GUIDE
to complete your settings.
Submit
PAGE 38/57
IP CAM User' s Guide
P
a
n
/
T
i
l
t
I
P
S
u
r
v
e
i
l
l
a
n
P
a
n
/
T
i
l
t
I
P
S
u
r
v
e
i
l
l
a
n
c
e
C
a
m
e
r
a
c
e
C
a
m
e
r
a
Rev. PV1.0
