Page 1: Network Camera
NETWORK CAMERA USER MANUAL Please read instructions thoroughly before operation and retain it for future reference. - Page 2 IMPORTANT SAFEGUARD All lead-free products offered by the company comply with the requirements of the European law on the Restriction of Hazardous Substances (RoHS) directive, which means our manufacture processes and products are strictly “lead-free” and without the hazardous substances cited in the directive. The crossed-out wheeled bin mark symbolizes that within the European Union the product must be collected separately at the product end-of-life.
- Page 3 MPEG4 Licensing THIS PRODUCT IS LICENSED UNDER THE MPEG4 VISUAL PATENT PORTFOLIO LICENSE FOR THE PERSONAL AND NON-COMMERCIAL USE OF A CONSUMER FOR (i) ENCODING VIDEO IN COMPLIANCE WITH THE MPEG4 VISUAL STANDARD (“MPEG-4 VIDEO”) AND/OR (ii) DECODING MPEG4 VIDEO THAT WAS ENCODED BY A CONSUMER ENGAGED IN A PERSONAL AND NON-COMMERCIAL ACTIVITY AND/OR WAS OBTAINED FROM A VIDEO PROVIDER LICENSED BY MPEG LA TO PROVIDE MPEG4 VIDEO.
-
Page 4: Table Of Contents
TABLE OF CONTENTS 1. OVERVIEW ............................1 1.1 Product Features ............................1 1.2 Package Content ............................1 1.3 Product Overview ............................1 1.4 Rear Panel ..............................1 1.5 Status Indicator............................2 2. CAMERA ACCESS WITH INTERNET EXPLORER ................3 2.1 Camera Login ............................3 2.2 Control Panel Overview .......................... -
Page 5: Overview
H.R. image sensor gives users clear and sharp pictures Remote Surveillance Fully compatibility on iPhone & iPad, and Internet Explorer® on Windows® operating system 1.2 Package Content □ Network camera □ Camera Bracket □ Quick Setup with iPhone / iPad □ Adapter 1.3 Product Overview... -
Page 6: Status Indicator
1.5 Status Indicator ICON LAN connection status Internet connection status System Status During powering on Always on Always on Blinking Always off (on 250 ms, off 250 ms) Reset default Blinking Blinking (on 250 ms, off 250 ms) (on 250 ms, off 250 ms) Upgrade ... -
Page 7: Camera Access With Internet Explorer
2. CAMERA ACCESS WITH INTERNET EXPLORER This network camera can be accessed via Microsoft® Internet Explorer® and iPhone / iPad / Android mobile devices with our self-developed program “EagleEyes” installed depending on different using situations. Note: For details about accessing network cameras via iPhone / iPad / Android mobile devices, please refer to http://www.eagleeyescctv.com. - Page 8 Function Icon User Level Description Supervisor / Power User Switch to the live view page. Live / Normal User / Guest Switch to the system configuration page, and the functions available for “Supervisor” and “Power User” are different. Config. Supervisor For details, please refer to “3.1 System configuration menu”...
-
Page 9: Camera Configurations
3. CAMERA CONFIGURATIONS Users can further configure this network camera by accessing via Internet Explorer. 3.1 System configuration menu Click “Config.” to enter the configuration page. Note: You need to be “Supervisor” to enter the system configuration page. If you’re not a “Supervisor”, please re-log into the camera with the correct user name and password. -
Page 10: Network
4. Download the video player to play the recorded data. 3.2 Network 3.2.1 Network You can set the network configuration of the network camera depending on your network type. For details, please refer to “Advanced Network Setup” from www.surveillance-download.com/user/n216.swf. 3.2.2 QoS QoS, Quality of Service, is the ability to control the data flow for real-time streaming. -
Page 11: Sntp
Function Description Once users choose the time zone, the network camera will adjust the local area time of the system automatically. NTP Server Simply use the default SNTP server (For example, tock.stdtime.gov.tw) or change to another server with which users are familiar. -
Page 12: Sms
4.4.7 SMS Note: Before using this function, you need to apply an API ID from the mobile messaging company, Clickatell, and you will be charged starting from the 11 message. For details, please refer to “APPENDIX 3 API ID APPLICATION FOR SMS MESSAGING’ at page 20. Enter the detailed information needed for text messaging, and click “Save”... -
Page 13: Upnp / Bonjour
Set the lock time in minutes when the maximum count of error login for an IP address is reached. Echo Request Select “Non-Block” to allow other users to use the ping command to detect the IP address of your network camera, or “Block” to deny the ping command request. -
Page 14: Rtp
IP address or port number is entered. Note: When the configurations are saved successfully, you’ll see a message indicating the IP address and port number assigned to this network camera. 3.2.10 RTP The Real-time Transport Protocol (RTP) is an Internet protocol standard to manage the real-time transmission of multimedia, such as VLC player. -
Page 15: Camera
3.3 Camera 3.3.1 Camera Rename the camera, and change the place where the camera name is shown on the screen, UP-LEFT / UP-RIGHT / DOWN-LEFT / DOWN-RIGHT. 3.3.2 Video Adjust video-related settings in different video format. “Quality” is related to image clearness. ... -
Page 16: Advance
3.3.4 Advance Adjust the camera parameters if necessary. Item Description Back Light It is the function to adjust the image to compensate for an area that is overpowered by brightness because of excessive light. The image will be properly exposed for clearness. Select to activate (ON) or disable (OFF) this function. Note: This function is available only in the day mode. -
Page 17: General
Item Description Click “Select All” to set the whole area under detection. Duration Set the duration time for trigger recording (5 / 10 / 20 / 40 seconds). Action Here defines how the camera delivers alerts to you for any event. Item Description E-Mail... -
Page 18: Time
3.5.2 Time Set daylight saving time and the current time, and click “Save” to confirm. Function Description Time Configuration Set the current date. Date Set the current time. Time Daylight Saving Time Configuration Specify whether to use daylight saving time (Enable / Disable). Daylight Saving Time If this function is enabled, set the time period (Start Time / End Time), and adjust the daylight saving time in hours (Adjust Time). -
Page 19: Online
3.5.4 Online You can check the current online user(s) with respective online information. To refresh the list, click “Reload”. To allow anonymous login, select “Enable” in “Anonymous Viewer Login”. To disable image code verification at login, select “No” in “Login with CAPTCHA Image”. 3.5.5 Account You can create a new account with different user access privilege, or delete or modify an existing account setting. -
Page 20: Google Maps
Step1: Click “Sign up for a Google Maps key” to enter the application page. Step2: Check the terms and conditions, and enter the IP address of the network camera. Then, click “Generate API Key”. Step3: Copy the generated API key, and click “Update Google Maps Key” on the web browser to paste it. - Page 21 Note: You’ll be prompted to keep current configurations. It’s recommended to keep them, or all configurations will be restored to default values after upgrade. Note: It takes a few minutes to finish the upgrade process. Do not disconnect the power during firmware upgrade, or the upgrade may be failed.
-
Page 22: Appendix 1 Product Specifications
APPENDIX 1 PRODUCT SPECIFICATIONS AVN216 ▓ Network Network Compression H.264 / MPEG4 / MJPEG Multiple Video Streaming 3 (H.264, MJPEG, MPEG4) (Encode Modes, IPS, Resolution) LAN Port LAN Speed 10/100 Based-T Ethernet DDNS, PPPoE, DHCP, NTP, SNTP, TCP/IP, ICMP, SMTP, FTP, Supported Protocols HTTP, RTP, RTSP, RTCP,IPv4, Bonjour, UPnP, DNS,UDP,IGMP, QoS ONVIF Compatible... -
Page 23: Appendix 2 Bit Rate Table For Reference
APPENDIX 2 BIT RATE TABLE FOR REFERENCE The data below is for reference only. The bit rates listed here may vary depending on the resolution, image quality & frame rate you choose, the complexity of your monitoring area, and how often the moving objects show in your monitoring area. Testing Environment ... -
Page 24: Appendix 3 Api Id Application For Sms Messaging
APPENDIX 3 API ID APPLICATION FOR SMS MESSAGING To allow the camera automatically sending a text message when an event happens, you need to apply an API ID from Clickatell, one mobile messaging company, first. Note: The SMS messaging is not totally free. You will be charged starting from the 11 message. - Page 25 Click the link in the Email to complete account activation, and enter the login page as follows. Enter the password you set, and click “Login”. Step3: Enter the mobile phone number (including your country code) you want the text message to be sent, and click “SEND ACTIVATION CODE”.
-
Page 26: Appendix 4 Q&A
APPENDIX 4 Q&A For more details about EagleEyes Q&A, please visit our official website: www.eagleeyescctv.com/supp_QnA.aspx. Question Answer I can connect to this camera in my house You didn’t configure this camera to Internet, but only in LAN. or office where it’s installed with wireless Please follow the steps in the advanced network setup guide to network.
