Physical IP Address
IP Share or LAN Hub
Network Setup for IP -CAM
Suitable Objects
1. Activate PPPoE function of IP share. Then, set another private IP address and activate
the DHCP server function of IP Share. When the dial-up of ADSL is successful, you will
get an float IP address from your ISP.
2. In the IP configuration for each IP-CAM, please assign different virtual IP address
internally and respectively. In the Http Port setting, please specify different port
parameters. (Please refer to 2.4-1 STATIC - IP Address Settings to type the IP
address properly.)
3.
For the port transformation in IP Share, please refer to IP and port settings of camera to
configure accordingly.
4.
For viewing images in IP-CAM from remote computer: Open IP browser and type in
the float IP address of ADSL and the port number of IP-CAM, e.g., http://
211.78.174.01:1025.
.
IP-CAM Network Framework Installation 4
Way to access Internet
Physical IP Address
IP CAM USER' S GUIDE
Owns one float IP address (dispatched by ISP
dynamically)
Must be equipped with DHCP and NAT
functions
LAN Enable / Manually
Web Server Port Number, need to be adjusted
Users with dial-up ADSL, one float IP address
and several IP-CAMs installed
Use Permanent ADSL or Cable Modem
Owns one physical IP address
PAGE 18/57
IP CAM User' s Guide
P
a
n
/
T
i
l
t
I
P
S
u
r
v
e
i
l
l
a
n
P
a
n
/
T
i
l
t
I
P
S
u
r
v
e
i
l
l
a
n
c
e
C
a
m
e
r
a
c
e
C
a
m
e
r
a
Rev. PV1.0
