change in the MD range. The lower the number entered, the higher the sensitivity of the
MD.
When motion is detected, the screen should display an MD warning in red in the upper left
hand corner if there is movement within MD1 or MD2, as shown in below:
- Any motion detection range can be selected in 640x480 and 320x240 resolutions
- In 160x120 resolution, the motion detection is fixed to the entire image.
Note:
1. Motion Detection can exist PC and SD Card
2.
Image that MD reaches PC is stored to C: \tmp\webmd
5. A
A
DVANCED
PPLICATION
This chapter explains the advanced settings for the IP CAM, including:

- Image Setup

- Capture View
- Network Setup
- Server Setup
- Event Trigger Setup
- Administration Setup
- Software Update
5.1 I
S
MAGE
ETUP
This includes
- Resolution Users can select between image resolution of 160x120, 320x240, and
640x480. The default resolution is 320x240.
- Quality
Users can select between " fine" , " normal" , and " basic" image quality. The
default image quality is " basic" .
- Anti-Flicker Users can select between 60Hz for USA and Canada, 50Hz for Australia
and Europe, or Outdoor for when you are observing a naturally lit outside area; The
default setting is 50Hz.
- Audio Audio output. Default setting is " off" .
- Rotate 180 This setting turns the image upside-down for when the camera is mounted to
IP CAM USER' S GUIDE
PAGE 34/57
IP CAM User' s Guide
P
a
n
/
T
i
l
t
I
P
S
u
r
v
e
i
l
l
a
n
P
a
n
/
T
i
l
t
I
P
S
u
r
v
e
i
l
l
a
n
c
e
C
a
m
e
r
a
c
e
C
a
m
e
r
a
Rev. PV1.0
