Settings!Menu - OM POWER OM2000+ User Manual

!
!
Second!and!!third!line!programmable!parameters!are:!
Forward!Power!
•
Reflected!Power!
•
Input!Power!
•
SWR!
•
TUNE!
•
Temperature!
•
Frequency!
•
Plate!voltage!–!Up!
•
Plate!current!–!Ip!
•
Screen!voltage!–!Us!
•
Screen!current!–!Is!
•
Screen!current!–!graph!
•
Grid!voltage!–!Ug!
•
Grid!current!Ig!
•
Heating!voltage!–!Uf!
•
!
5.2.2. Settings'menu'
'
Settings! menu! offers! EBS! settings,! factory! default! parameters! restoring! and! display! contrast! settings!
(software!version!6.1.!or!higher).!
!
!
!
S2!and!S3!now!changed!their!functions.!!
To!edit!left!side!of!the!second!line,!press!LEFT'
button.!
!
!
Go!UP!or!DOWN!to!select!desired!parameter.!
Press!ENT!to!confirm!selection.!
!
!
!
If!you!finish!left!side!settings,!press!ESC!to!go!
back!to!the!side!selection.!
To! start! edit! right! side,! press! RIGHT)
button....etc.!
