OM POWER OM2000+ User Manual page 25

!
Press!OPER!to!enter!operation!mode.!Apply!low)input)power!and!press!PTT.!Be!sure!you!selected!right!
BAND,!TUNE!and!LOAD!knob!positions.!!If!you!made!some!mistake,!fault!message!appears:!
!
Another!mistake!can!occur,!if!you!have!antenna!connected!to!the!wrong!output.!In!such!a!case!„SWR)
is)too)high"!error!message!appears.!Change!antenna!output!using!S4!button.!
!
!
the!display.!
!
!
!
!
Safety! circuit! stopped! transmitting,! fault! LED!
is!ON!(Fault!code!4!is!saving!to!the!memory).!!
Release! PTT,! set! proper! positions! of! BAND,!
TUNE! and! LOAD! according! to! the! table! and!
press)PTT!again.!
!
This! is! not! an! optimal! result,! TUNE! indicator!
must! go! between! both! arrows.! Use! TUNE!
knob! to) get) maximum) output) power) and!
LOAD!knob!to!get)indicator)between)arrows.!!
!
Another! example! of! not! optimal! result,! TUNE!
indicator! must! go! between! both! arrows.! Use!
TUNE! knob! to) get) maximum) output) power)
and! LOAD! knob! to! get) indicator) between)
arrows)(in!arrows!direction).!
!
!
This!is!a!good)result!of!tuning.!
!
Now!increase!input!power!slowly!and!watch!
Exhibit!6!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!Page!25!!from!35!
!
!
!
!
!
