Siemens Simovert Masterdrives Operating Instructions Manual page 193

08.2009
Order No. Rated
input cross-section
6SE70... current VDE
[A]
[mm²]
6.1
16-1EA 1 1.5
8.0
18-0EA 1 1.5
10.2
21-0EA 1 2.5
13.2
21-3EB 1 2.5
17.5
21-8EB 1 4
25.5
22-6EC 1 10
34.0
23-4EC 1 16
37.5
23-8ED 1 16
47.0
24-7ED 1 25
59.0
26-0ED 1 25
27-2ED 1 72.0 50
NOTE
WARNING
Siemens Controls
Siemens AG 6SE7087-6JD50
SIMOVERT MASTERDRIVES
Line side
Recommended fuse
AWG gR (SITOR) gL NH
[A] 3NE [A]
16 16 --- 10
16 16 1813-0 16
14 16 1813-0 16
14 20 1814-0 25
10 25 1815-0 25
6 35 1803-0 35
4 40 1802-0 50
4 50 1817-0 63
2 63 1818-0 63
2 80 1820-0
100
00 80 1820-0
100
AWG: American Wire Gauge
1) : The indicated fuses are only valid for converters with AC 3-phase 500 V
input voltage. For converter with a higher input voltage, fuses up to 660 V
must be used. The order numbers of these fuses can be obtained by adding
on the corresponding 500 V fuse "-6".
e.g.: for 500 V
for 660 V
= 5 corresponds to MASTERDRIVES Motion Control
= 7 corresponds to MASTERDRIVES Motion Control Performance 2
Table 7-1 Cross-sections, fuses
The connection cross-sections are determined for copper cables at
40 °C (104 °F) ambient temperature and cables with a permissible
operating temperature at the conductor of 70 °C (installation type C in
accordance with DIN VDE 0298-4 / 08.03).
gL fuses only provide reliable protection to the cables, and not to the
semiconductors.
If the units are connected to the supply system without a main contactor
which can interrupt the incoming supply in the event of a fault, the unit
may suffer further damage.
Operating Instructions
North America
1)
3NA Type [V]
3803 600
AJT,LPJ
3805 AJT,LPJ 600
3805 600
AJT,LPJ
3810 600
AJT,LPJ
3810 600
AJT,LPJ
3814 AJT,LPJ 600
3820 AJT,LPJ 600
3822 600
AJT,LPJ
3822 600
AJT,LPJ
3830 600
AJT,LPJ
3830 AJT,LPJ 600
3NA3803
3NA3803-6
Connecting-up
Motor side
Line cross-section
reactor VDE
[A] 4EP [mm²]
8 3200-1US 1.5
12 3400-2US 1.5
15 3400-1US 1.5
17.5 3500-0US 2.5
25 3600-4US 2.5
35 3600-5US 10
45 3700-2US 10
50 3700-5US 16
60 3800-2US 16
80 3800-7US 16
90 3900-2US 25
7-5
AWG
16
16
16
14
14
6
6
4
4
4
2
