SIMATIC NET

Industrial Ethernet switches

SCALANCE X-100 media converter

Operating Instructions

12/2023

C79000-G8976-C346-07

Introduction

Safety notes

Network topologies

Description of the device

Installation and

disassembly

Connecting up

Maintenance

Technical specifications

Dimension drawings

Approvals

Need help?

Do you have a question about the SIMATIC NET SCALANCE X-100 and is the answer not in the manual?

Questions and answers

Summary of Contents for Siemens SIMATIC NET SCALANCE X-100

Page 1 Introduction Safety notes Network topologies SIMATIC NET Description of the device Industrial Ethernet switches SCALANCE X-100 media converter Installation and disassembly Connecting up Operating Instructions Maintenance Technical specifications Dimension drawings Approvals 12/2023 C79000-G8976-C346-07...
Page 2 Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.
Page 3 Table of contents Introduction ............................5 On the Operating Instructions ....................5 Cybersecurity information ....................6 Safety notes ............................9 Network topologies ..........................11 Possible network topologies ....................11 Coupling of network segments................... 13 Cascading two media converters ..................14 Description of the device ........................
Page 4 Table of contents Grounding ......................... 44 IE FC RJ-45 Plug 180......................45 Maintenance............................47 Technical specifications ........................49 SCALANCE X101-1 ......................49 SCALANCE X101-1LD ......................51 Dimension drawings ..........................55 Approvals ............................. 59 Index ..............................67 SCALANCE X-100 media converter Operating Instructions, 12/2023, C79000-G8976-C346-07...
Page 5 • On the data medium that ships with some products: – Product CD / product DVD – SIMATIC NET Manual Collection • On the Internet pages of Siemens Industry Online Support: – Industrial Ethernet / PROFINET Industrial Ethernet System Manual (https:// support.industry.siemens.com/cs/ww/en/view/27069465)
Page 6 Siemens’ products and solutions undergo continuous development to make them more secure. Siemens strongly recommends that product updates are applied as soon as they are available and that the latest product versions are used. Use of product versions that are no longer supported, and failure to apply the latest updates may increase customer’s exposure...
Page 7 RSS Feed under https://new.siemens.com/cert (https://www.siemens.com/cert). Catalogs You will find the article numbers for the Siemens products of relevance here in the following catalogs: • SIMATIC NET Industrial Communication / Industrial Identification, catalog IK PI • SIMATIC Products for Totally Integrated Automation and Micro Automation, catalog ST 70 •...
Page 8 Introduction 1.2 Cybersecurity information Electrostatic discharge NOTICE Electrostatic sensitive devices (ESD) Electronic modules contain electrostatic sensitive components These components can easily be destroyed if handled incorrectly. Note the following instructions to avoid damage. • Touch electronic modules only when you absolutely need to work on them. •...
Page 9 Safety notes Read the safety notices Note the following safety notices. These relate to the entire working life of the device. You should also read the safety notices relating to handling in the individual sections, particularly in the sections "Installation" and "Connecting up". CAUTION To prevent injury and damage, read the manual before using the device.
Page 10 Safety notes SCALANCE X-100 media converter Operating Instructions, 12/2023, C79000-G8976-C346-07...
Page 11 Network topologies Possible network topologies Switching technology allows extensive networks to be set up with numerous nodes and simplifies network expansion. Which topologies can be implemented? Using the media converters of the SCALANCE X-100 product line, you can implement bus and star topologies.
Page 12 Network topologies 3.1 Possible network topologies Star topology The following figure shows an optical star structure with the IE switches X-400 and X106-1. A SCALANCE W access point and SIMATIC NET 200 systems are electrically connected via the media converters SCALANCE X101-1 or SCALANCE X101-1LD. Figure 3-2 Example of an optical star topology with SCALANCE X101-1 or SCALANCE X101-1LD SCALANCE X-100 media converter...
Page 13 Network topologies 3.2 Coupling of network segments Ring topology The following figure shows an electrical ring with a SCALANCE X204IRT as redundancy manager and SCALANCE X208 IE switches. Using the media converters SCALANCE X101-1 or SCALANCE X101-1LD, there is a conversion to an optical section. Figure 3-3 Example of an electrical ring with SCALANCE X101-1 or SCALANCE X101-1LD Coupling of network segments...
Page 14 Network topologies 3.3 Cascading two media converters Figure 3-4 Example of a standby coupling of two redundant rings Cascading two media converters You can connect two media converters of the same type in series, i.e. connect them to each other via the FO port. Both media converters must be operated in Transparent Link Mode for the cascade.
Page 15 Network topologies 3.3 Cascading two media converters Ethernet interface for devices that are electrically connected and the link is not established. This behavior cannot be influenced and occurs particularly when plants are switched on. Use the new SCALANCE XCM102 media converters with corresponding SFPs for such applications.
Page 16 Network topologies 3.3 Cascading two media converters SCALANCE X-100 media converter Operating Instructions, 12/2023, C79000-G8976-C346-07...
Page 17 Description of the device Purpose What is possible? The media converters of the SCALANCE X-100 allow the cost-effective installation of Industrial Ethernet linear (bus) and star structures with transitions from one media to another. The passive use of two identical SCALANCE X-100 media converters in series (cascaded) within a redundant ring is possible.
Page 18 Description of the device 4.2 Product overview 4.2.1 Overview of the SCALANCE X-100 media converters Table 4-1 Overview of the product characteristics Properties X101-1 X101-1LD SIMATIC environment Diagnostics LED 24 VDC 2 x 24 VDC Compact housing 40 mm (securing collar, etc.) Signaling contact + on-site operation Diagnostics: Web, SNMP, PROFINET C-PLUG...
Page 19 Description of the device 4.2 Product overview Unpacking and checking WARNING Do not use any parts that show evidence of damage If you use damaged parts, there is no guarantee that the device will function according to the specification. If you use damaged parts, this can lead to the following problems: •...
Page 20 Description of the device 4.3 Product properties and device views Product properties and device views 4.3.1 SCALANCE X101-1 Possible attachments The SCALANCE X101-1 media converter has an RJ-45 jack and a BFOC socket for connecting end devices or further network segments. Note The BFOC socket (Bayonet Fiber Optic Connector) corresponds to the ST socket.
Page 21 Description of the device 4.3 Product properties and device views 4.3.2 SCALANCE X101-1LD Possible attachments The SCALANCE X101-1LD media converter has an RJ-45 jack and a BFOC socket for connecting end devices or further network segments. Note The BFOC socket (Bayonet Fiber Optic Connector) corresponds to the ST socket. Figure 4-2 SCALANCE X101-1LD SCALANCE X-100 media converter...
Page 22 Description of the device 4.4 TP ports (twisted pair) TP ports (twisted pair) RJ-45 connector pinout With SCALANCE X-100 media converters, the twisted-pair port is designed as an RJ-45 jack with the MDI-X pin assignment (Medium Dependent Interface Autocrossover) of a network component.
Page 23 Description of the device 4.5 FO port (fiber optic) Two components connected to a link segment can exchange information about the data transfer and can adapt their settings to each other. The mode with the highest possible speed is set. Note Devices not supporting autonegotiation must be set permanently to 100 Mbps half duplex or 10 Mbps half duplex.
Page 24 Description of the device 4.5 FO port (fiber optic) NOTICE No link building with active plug-in transceivers If you connect a SCALANCE X101-1 or SCALANCE X101-1LD media converter to the port of a partner device in which an active plug-in transceiver is plugged in, the media converter does not establish a link.
Page 25 Description of the device 4.5 FO port (fiber optic) Range The maximum transmission range (segment length) is as follows: • with 62.5/125 µm fiber multimode SIMATIC NET cable: 4 km • with 50.0/125 µm fiber multimode SIMATIC NET cable: 5 km Connectors The cables are connected using BFOC sockets. 4.5.2 SCALANCE X101-1LD Transmission speed...
Page 26 Description of the device 4.6 LEDs Connectors The cables are connected using BFOC sockets. GI-PCF For segment lengths longer than 100 m, you can use GI-PCF cables. Note the information of the manufacturer. LEDs Fault LED "F" (red LED) The fault LED indicates the incorrect functioning of the device. LED color LED status Meaning...
Page 27 Description of the device 4.7 SET button LED color LED status Port LED Meaning Yellow Link exists, data reception at port Yellow Flashing P1 + P2 Setting or display of the fault mask Note In standalone mode, the link status of the port LEDs is only displayed if the same link status is detected at both ports P1 and P2.
Page 28 Description of the device 4.7 SET button Phase Description LEDs flash at 5 Hz The currently set fault mask is displayed. The LEDs of the monitored ports flash. If no fault mask is set, all port LEDs flash one after the other. If you release the button in phase 1, this has no effect.
Page 29 Description of the device 4.7 SET button Disabling transparent link mode To disable the transparent link mode, press the SET button and keep it pressed for 0.5 seconds. The transparent link LED is off. The transparent link mode is disabled. The media converter is in standalone mode.
Page 30 Description of the device 4.7 SET button SCALANCE X-100 media converter Operating Instructions, 12/2023, C79000-G8976-C346-07...
Page 31 Installation and disassembly Safety notices for installation Safety notices When installing the device, keep to the safety notices listed below. WARNING Ambient temperature above 55 °C If a device is operated in an ambient temperature of more than 55 °C, the temperature of the device housing may be higher than 70 °C.
Page 32 Installation and disassembly 5.1 Safety notices for installation Safety notices on use in hazardous areas General safety notices relating to protection against explosion WARNING EXPLOSION HAZARD Replacing components may impair suitability for Class 1, Division 2 or Zone 2. WARNING The device is intended for indoor use only. WARNING The device may only be operated in an environment of contamination class 1 or 2 (see EN/IEC 60664-1, GB/T 16935.1).
Page 33 Installation and disassembly 5.3 Installation on a DIN rail Types of installation The devices can be installed in the following ways: • Installation on a 35 mm DIN rail • Installation on a SIMATIC S7-300 standard rail • Wall mounting Installation clearance Keep to the minimum clearances so that the convection ventilation of the device is not blocked.
Page 34 Installation and disassembly 5.3 Installation on a DIN rail Figure 5-1 Installation on a 35 mm DIN rail Removal To remove the device from the DIN rail, follow the steps below: 1. Disconnect all connected cables. 2. Pull out the terminal blocks for the power supply and the signaling contact. 3.
Page 35 Installation and disassembly 5.4 Installation on a standard rail Figure 5-2 Removal from a 35 mm DIN rail Installation on a standard rail Installation on a SIMATIC S7-300 standard rail To install the device on an S7-300 standard rail, follow the steps below: 1.
Page 36 Installation and disassembly 5.5 Wall mounting 4. Fit the connectors for the signaling contacts. See also section "Signaling contacts (Page 43)". 5. Insert the terminal blocks into the sockets on the device. Figure 5-3 Standard rail mounting X-100MC Removal To remove the device from the S7-300 standard rail, follow the steps below: 1.
Page 37 Installation and disassembly 5.6 Disassembly 3. Fit the connectors for the signaling contacts. See also section "Signaling contacts (Page 43)". 4. Insert the terminal blocks into the sockets on the device. 5. Screw the device to the wall. Note The wall mounting must be capable of supporting at least four times the weight of the device. Disassembly WARNING Improper disassembly...
Page 38 Installation and disassembly 5.6 Disassembly SCALANCE X-100 media converter Operating Instructions, 12/2023, C79000-G8976-C346-07...
Page 39 Connecting up Safety when connecting up Safety notices When connecting up the device, keep to the safety notices listed below. WARNING Power supply The device is designed for operation with a directly connectable safety extra low voltage (SELV) from a limited power source (LPS). The power supply therefore needs to meet at least one of the following conditions: •...
Page 40 Connecting up 6.1 Safety when connecting up Safety notices on use in hazardous areas General safety notices relating to protection against explosion WARNING EXPLOSION HAZARD Do not connect or disconnect cables to or from the device when a flammable or combustible atmosphere is present.
Page 41 Connecting up 6.1 Safety when connecting up WARNING Improper installation of shielded cables There is a risk of explosion due to equalizing currents between the hazardous area and the non- hazardous area. • Ground shielded cables that cross hazardous areas at one end only. •...
Page 42 Connecting up 6.3 Power supply Wiring rules When wiring use cables with the following AWG categories or cross sections. Wiring rules for ... Screw/spring-loaded ter‐ minals connectable cable cross sec‐ without wire end ferrule 0.25 - 2.5 mm tions for flexible cables ... AWG: 24 - 13 with wire end ferrule with plastic fer‐...
Page 43 Connecting up 6.4 Signaling contact Pin number Assignment Pin 1 L1+ (24 VDC) Pin 2 M1 (ground) Pin 3 M2 (ground) Pin 4 L2+ (24 VDC) WARNING Incorrect power supply The power supply unit to supply the device must comply with NEC Class 2 (voltage range 18 - 32 V, current requirement 350 mA).
Page 44 Connecting up 6.5 Grounding Pin number Assignment Pin 1 Pin 2 The following errors/faults can be signaled by the signaling contact: • The failure of a link on one of the two monitored ports. • The failure of one of the two redundant power supplies. The connection or disconnection of a communication node on an unmonitored port does not lead to an error message.
Page 45 Connecting up 6.6 IE FC RJ-45 Plug 180 IE FC RJ-45 Plug 180 The rugged node connectors are designed for industry with PROFINET-compliant connectors and provide additional strain and bending relief with a locking mechanism on the casing. Fitting the IE FC RJ45 Plug 180 to the IE FC Standard Cable You will find the notes on installation in the instructions that ship with the IE FC RJ45 Plug 180.
Page 46 Connecting up 6.6 IE FC RJ-45 Plug 180 Plugging in the IE FC RJ45 Plug 180 Plug the IE FC RJ45 Plug 180 into the twisted-pair port of the device until it locks in place. Figure 6-2 Plugging in the IE FC RJ45 Plug 180 With its tight fit and locking mechanism with the PROFINET-compliant male connector IE FC RJ45 Plug 180, the securing collar on the TP port of the device ensures a rugged node attachment that provides strain and bending relief for the RJ-45 jack.
Page 47 Maintenance WARNING Unauthorized repair of devices in explosion-proof design Risk of explosion in hazardous areas • Repair work may only be performed by personnel authorized by Siemens. WARNING Impermissible accessories and spare parts Risk of explosion in hazardous areas • Only use original accessories (Page 18) and original spare parts.
Page 48 Maintenance Device defective If any other fault develops, please send the device to your SIEMENS service center for repair. Repairs on-site are not possible. SCALANCE X-100 media converter Operating Instructions, 12/2023, C79000-G8976-C346-07...
Page 49 Technical specifications SCALANCE X101-1 Table 8-1 Technical specifications of the SCALANCE X101-1 Technical specifications Order number SCALANCE X101-1 6GK5101-1BB00-2AA3 Attachment to Industrial Ethernet Quantity Design RJ-45 jack with MDI‑X pinning Properties Full duplex Transmission speed 100 Mbps Optical connectors Quantity Design BFOC socket Properties...
Page 50 Technical specifications 8.1 SCALANCE X101-1 Technical specifications Current consumption Typical 120 mA Minimum rated current of the power 170 mA supply unit Power loss at 24 VDC Typical 3 W Overvoltage protection at input PTC resettable fuse (0.5 A / 60 V) Permitted ambient conditions Ambient temperature During operation...
Page 51 Technical specifications 8.2 SCALANCE X101-1LD Note Temperature code for c-UL-us for hazardous locations, FM and ATEX Zone 2 You will find the temperature code "T.." or the maximum ambient temperature "Ta: .." on the type plate. SCALANCE X101-1LD Table 8-2 Technical specifications of the SCALANCE X101-1LD Technical specifications Order number SCALANCE X101-1LD...
Page 52 Technical specifications 8.2 SCALANCE X101-1LD Technical specifications Current consumption Typical 120 mA Minimum rated current of the power 200 mA supply unit Power loss at 24 VDC Typical 3 W Overvoltage protection at input PTC resettable fuse (0.5 A / 60 V) Permitted ambient conditions Ambient temperature During operation...
Page 53 Technical specifications 8.2 SCALANCE X101-1LD Note Temperature code for c-UL-us for hazardous locations, FM and ATEX Zone 2 You will find the temperature code "T.." or the maximum ambient temperature "Ta: .." on the type plate. SCALANCE X-100 media converter Operating Instructions, 12/2023, C79000-G8976-C346-07...
Page 54 Technical specifications 8.2 SCALANCE X101-1LD SCALANCE X-100 media converter Operating Instructions, 12/2023, C79000-G8976-C346-07...
Page 55 Dimension drawings Figure 9-1 Dimension drawing, rear view SCALANCE X-100 media converter Operating Instructions, 12/2023, C79000-G8976-C346-07...
Page 56 Dimension drawings Figure 9-2 Dimension drawing, side view SCALANCE X-100 media converter Operating Instructions, 12/2023, C79000-G8976-C346-07...
Page 57 Dimension drawings Figure 9-3 Dimension drawing, bending radii SCALANCE X-100 media converter Operating Instructions, 12/2023, C79000-G8976-C346-07...
Page 58 Dimension drawings SCALANCE X-100 media converter Operating Instructions, 12/2023, C79000-G8976-C346-07...
Page 59 Current approvals on the Internet You will find the current approvals for the product on the Internet pages of Siemens Industry Online Support (https://support.industry.siemens.com/cs/ww/en/ps/15273/cert). Notes for the manufacturers of machines This product is not a machine in the sense of the EC Machinery Directive or the Supply of Machinery (Safety) Regulations (UK).
Page 60 DE-76181 Karlsruhe Germany Importer UK: Siemens plc, Manchester M20 2UR You can find the current UK Declaration of Conformity for these products on the Internet pages under Siemens Industry Online Support (https:// support.industry.siemens.com/cs/ww/en/ps/15273/cert). SCALANCE X-100 media converter Operating Instructions, 12/2023, C79000-G8976-C346-07...
Page 61 "SIMATIC NET Product Information Use of subassemblies/modules in a Zone 2 Hazardous Area". You will find this document • on the data medium that ships with some devices. • on the Internet pages under Siemens Industry Online Support (https:// support.industry.siemens.com/cs/ww/en/view/78381013).
Page 62 Approvals Note for devices with CLASS 1 LASER Important note on products certified according to Type Examination Certificate KEMA 07ATEX0145 X as of Issue 95 / DEKRA 18ATEX0025 X and IECEx Certificate of Conformity DEK 14.0025X as of Issue 43 / DEK 18.0017X and containing Class 1 optical radiation sources. Note CLASS 1 LASER The device contains optical radiation sources which comply with the limits of Class 1 according...
Page 63 Approvals cULus for Hazardous Locations ANSI/ISA 12.12.01-2007, CSA C22.2 No. 213-M1987 CL. 1, Div. 2 GP. A.B.C.D T.. CL. 1, Zone 2, GP, IIC, T.. (T.. = For detailed information on the temperature class, refer to the type plate) cULus Approval for Information Technology Equipment cULus Listed I.
Page 64 • "Industrial Ethernet / PROFINET Industrial Ethernet" System Manual (https:// support.industry.siemens.com/cs/ww/en/view/27069465) • "Industrial Ethernet / PROFINET - Passive Network Components" System Manual (https:// support.industry.siemens.com/cs/ww/en/view/84922825) • "EMC Installation Guidelines" configuration manual (https:// support.industry.siemens.com/cs/ww/en/view/60612658)
Page 65 Approvals WARNING Personal injury and property damage can occur The installation of expansions that are not approved for SIMATIC NET products or their target systems may violate the requirements and regulations for safety and electromagnetic compatibility. Only use expansions that are approved for the system. Note The test was performed with a device and a connected communications partner that also meets the requirements of the standards listed above.
Page 66 Approvals SCALANCE X-100 media converter Operating Instructions, 12/2023, C79000-G8976-C346-07...
Page 67 Index FO port, 24 SCALANCE X101-1, 24 SCALANCE X101-1LD, 25 Accessories, 19 Approvals, 59 Article numbers, 17 Attachment to Industrial Ethernet, 49, 51 GI-PCF, 26 Auto polarity exchange, 23 Glossary, 6 Autonegotiation, 22 Grounding, 44 Installation on a DIN rail, 44 S7 standard rail, 44 Wall mounting, 44 Bus topology, 11 IE FC RJ-45 Plug 180, 45 Installation, 45 Cable type, 18 Plugging in, 46...
Page 68 Index Frame delay time, 52 Optical connectors, 51 Optical parameters, 51 Order numbers, 51 Optical connectors, 49, 51 Permitted ambient conditions, 52 Optical parameters, 49, 51 Permitted cable lengths, 51 Order numbers, 49, 51 Switching properties, 52 Scope of delivery, 19 Sender, 25 SCALANCE X101-1LD, 25 Permitted ambient conditions, 50, 52 SET button, 27 Permitted cable lengths, 22, 49, 51 Function, 27 Pin assignment, 22 Signaling contact, 43...
