3.5 Processing Time for Each Command When PG-FP5 Is in Use (Reference Value)

The following shows the processing time for each command (reference value) when PG-FP5 is used as a dedicated
flash memory programmer.
Table 3 – 10 Processing Time for Each Command When PG-FP5 Is in Use (Reference Value)
Erasing
Writing
Verification
Writing after erasing
Remark The command processing times (reference values) shown in the table are typical values under the
following conditions.
Port: TOOL0 (single-line UART)
Speed: 1,000,000 bps
Mode: Full speed mode (flash operation mode: HS (high speed main) mode)
R02UH0004EJ0110 Rev.1.10
Dec 16, 2016
PG-FP5 Command
CHAPTER 3 FLASH MEMORY
256 Kbytes Code Flash
2.5 s
6 s
5.5 s
8 s
