4.4 RF Transceiver Characteristics

4.4.1 RF transmission characteristics

(T = +25°C, V = 3.0 V, f = 2402 to 2480 MHz, GND = 0 V)
A DD
Parameter
RF frequency range
Maximum transmitted outp
power
Frequency tolerance

4.4.2 RF reception characteristics

(T = +25°C, V = 3.0 V, f = 2402 to 2480 MHz, GND = 0 V)
A DD
Parameter
RF frequency range
Maximum input level
Receiver sensitivity
R02UH0004EJ0110 Rev.1.10
Dec 16, 2016
Symbol Condition
RF
CF
RF RF low power mode
POWER
RF normal mode
RF high performance mode
°C
RF -25 to +75
TXFERR
Symbol Condition
RF
CF
RF
PER ≤ 30.8%
LEVEL
RF
PER ≤ 30.8%
STY
ideal
PER ≤ 30.8%
dirty
CHAPTER 4 ELECTRICAL SPECIFICATIONS
MIN.
2402
MIN.
2402
RF low power mode
RF normal mode
RF high performanc
mode
RF normal mode
TYP. MAX.
2480
-15
0
0
-50 +50
TYP. MAX
2480
0
-60
-90
-92
-70
Unit
MHz
dBm
dBm
dBm
ppm
Unit
MHz
dBm
dBm
dBm
dBm
dBm
