  • Page 1 User Guide UG000292 TDC-GP30 Reference Board GP30-DEV-KIT v1-00 • 2019-Feb-26...

  • Page 2: Table Of Contents

    Ultrasonic Measurement Control ....13 Temperature Measurement Control ... 14 Legal Information ......40 General Control .......... 15 Interfaces ............ 16 Interrupt & Error Handling ......17 ams ............. 18 Demo Kit Manual • PUBLIC UG000292 • v1-00 • 2019-Feb-26 │ 2...

  • Page 3: Introduction

    Introduction Introduction The GP30-DEV-KIT is a platform for a quick and easy start-up and evaluation of the TDC-GP30 ultrasonic flow converter (UFC). It supports the QFN32 package, which offers the functionality need for standard water and heat meters. The development kit offers user-friendly configuration and extensive testing of the TDC-GP30, but also the complete assembler environment for programming the device.

  • Page 4: Ordering Information

    Document Feedback TDC-GP30 Introduction Ordering Information Part Number Description Ordering Code TDC-GP30 Demo Kit for QFN32 version GP30-DEV-KIT 220260003 including PICOPROG and cables GP30-DEMO-KIT-F01 220260006 TDC-GP30 Demo Kit with firmware for QFN32 version including PICOPROG and cables GP30-DEMO MODULE 220260002...

  • Page 5: Quick Start Guide

    Connect your spool piece to US_UP and US_DOWN Quick Start for Initial Measurements From the “Start” menu, go to “All Programs” and then to the “ams” directory. Double click the “GP30_v1_7_0” icon (or newer versions, if available) to begin execution of the evaluation software.
  • Page 6 Document Feedback TDC-GP30 Quick Start Guide Figure 2: Measurement Page ● Click the “Verify Interface” button to confirm communication between PICOPROG V3.0 and TDC-GP30 is working. Both fields, “Pico Prog FW version” and “Comm. With GP30 OK?”, should become green. ●...
  • Page 7 If PICOPROG is not displayed correctly then go to the drivers folder, e.g. C:\Program Files (x86)\ams\GP30\data\ and install the driver for your operating system manually. In case of an upgrade of the software to a newer version, please make sure that the software uses the latest driver. For manual installation open the USB communications window and check the firmware version of the PICOPROG.

  • Page 8: Hardware Description

    Document Feedback TDC-GP30 Hardware Description Hardware Description Introduction The GP30-DEMO MODULE board, shown in Figure 5, is a front-end for a water or heat meters. The transducers and temperature sensors are directly connected to this board. It comes with a 32.768 kHz quartz (X2) and a 4 MHz ceramic oscillator (X1).
  • Page 9 Document Feedback TDC-GP30 Hardware Description soon as the GP30 evaluation software starts, a special firmware is written into the PICOPROG to handle the SPI or UART communication with the TDC-GP30. The PICOPROG is now listed as “UNIPRO” in the device manager. For SPI communication only, PICOPROG version 2.0 is sufficient.

  • Page 10: Software Description

    First Step with Measurement Control Elements A good first step is to load a working configuration and make measurements in frontend mode (without using the internal 32-Bit µP). ams provides a sample configuration file named GP30Y_config_default_A1.A2.11.03 which typically works well with DN20 spool pieces.
  • Page 11 Document Feedback TDC-GP30 Software Description Press “System Reset” button. Now the PICOPROG FW version field should get green and the appropriate version should be displayed (20 or higher). Further, “Comm GP30 OK?” should get green to show that communication with TDC-GP30 works. If watchdog is not disabled by “System Reset”.
  • Page 12 Document Feedback TDC-GP30 Software Description It is possible to activate up to four plots. Each plot has various selections, e.g. TOF1UP, TOF2UP etc.. Always averaged values are displayed. Figure 9: TOF Graph The measurement data can be exported into text files, either the main values for calibration only, or the full data.

  • Page 13: Ultrasonic Measurement Control

    Document Feedback TDC-GP30 Software Description 4.1.3 2-Wire Temperature Measurement Results A graph to display temperature measurement results opens in a separate window by “Temperature Graph” button, similar to TOF graph. Figure 12: Temperature Measurement Results Graph Ultrasonic Measurement Control In this tab the user makes all settings for an appropriate ultrasonic measurement. They group as follows: ●...

  • Page 14: Temperature Measurement Control

    Document Feedback TDC-GP30 Software Description Figure 13: Ultrasonic Measurement Control Tab The meanings of the various settings are displayed in clear text. For more details about the register settings please refer to the GP30 manual. Temperature Measurement Control All settings for an appropriate temperature measurement are done in this tab, which are grouped as follows: ●...

  • Page 15: General Control

    Document Feedback TDC-GP30 Software Description Figure 14: Temperature Measurement Control Tab The meanings of the various settings are displayed in clear text. For more details about the register settings please refer to the GP30 manual. General Control The “General Control” tab covers configuration settings for ●...

  • Page 16: Interfaces

    Document Feedback TDC-GP30 Software Description Figure 15: General Control Tab The meanings of the various settings are displayed in clear text. For more details about the register settings please refer to the GP30 manual 4.4.1 Firmware In case the TDC-GP30 has firmware, setting flag “Enable post processing” turns on the CPU (flow meter mode).

  • Page 17: Interrupt & Error Handling

    Document Feedback TDC-GP30 Software Description Figure 16: Interfaces Tab The meanings of the various settings are displayed in clear text. For more details about the register settings please refer to the GP30 manual. 4.5.1 Pulse Interface The pulse interface needs an appropriate firmware in the chip. The settings in the evaluation software only generate an artificial pulse to test the general functionality.

  • Page 18: Ams

    Firmware Parameters and Firmware Error Counters Those two tabs display and allow editing of parameters related to the ams flow firmware. They are of use only for TDC-GP30-F01. For details please refer to the datasheet TDC-GP30 Vol.4 Firmware Overview.
  • Page 19 Document Feedback TDC-GP30 Software Description Figure 18: Firmware Parameters Tab Figure 19: Firmware Error Counters Demo Kit Manual • PUBLIC UG000292 • v1-00 • 2019-Feb-26 │ 19...

  • Page 20: Software Menu

    Document Feedback TDC-GP30 Software Menu Software Menu Beside main window, the software menu allows the opening of other windows. There are some menu items which are redundant to available buttons of main window. File ● Open Config This dialog box allows the path selection of a configuration file, covering the register settings, necessary for a proper configuration of the GP30.
  • Page 21 Document Feedback TDC-GP30 Software Menu ● RAM Memory Figure 20: RAM Memory Access ● Opens a window which allows single write and read accesses to random access area for addresses 0x000 – 0x0FF. ● The random access area from 0x100 – 0x17F, containing the firmware data, can be accessed separately by “Firmware Download”...

  • Page 22: Firmware

    Document Feedback TDC-GP30 Software Menu ● Remote Commands This window summarizes some additional commands, which can be executed via remote interface. Figure 22: Remote Commands ● System Reset: Executes a complete system reset of GP30. Same function as “System Reset” button in “Measurement” tab of main window ●...
  • Page 23 Document Feedback TDC-GP30 Software Menu Figure 23: Firmware Menu The following window comes up: Demo Kit Manual • PUBLIC UG000292 • v1-00 • 2019-Feb-26 │ 23...
  • Page 24 Document Feedback TDC-GP30 Software Menu Figure 24: Assembler Window This is a comfortable editor with syntax highlighting, search and replace, copy and paste functions. Under menu item “Assembler” the user finds the compile and download options. The download option effects, that “Firmware Download” window is opened (see also below). Whether the call of these functions was successful or not is indicated by the messages at the bottom of the assembler window.
  • Page 25 TDC-GP30 Software Menu “Firmware User Code” is either one of ams firmware examples, either the customers code or in case of chips with ams firmware (TDC-GP30-F01) the open source part. The FW Data 1 and 2 include firmware relevant coefficients and the configuration. The figure below shows an example for anTDC- GP30-F01 application.
  • Page 26 ● CPU Values This tab is only for customer who uses the ams firmware for flow calculation. It reads out some important CPU values like water temperature, flow, velocity, etc. To enable the readout the “Read calculated values” checkbox has to be set.

  • Page 27: Help

    Document Feedback TDC-GP30 Software Menu Figure 28: Flow Calculation Tab Set for using on-chip firmware Help When moving the cursor over the values in tabs of main window, the parameter name (used in the GP30 manual) is displayed. By right-click and selection of “Description and Tip”, a window is opened showing additional description of the value.
  • Page 28 Not supported in this software revision. ● USB Communication Figure 30: USB Communications As described in chapter “Software Installation”. ● About Displays software version number together with general information about software and ams. Demo Kit Manual • PUBLIC UG000292 • v1-00 • 2019-Feb-26 │ 28...

  • Page 29: Schematics, Layers And Bom

    Document Feedback TDC-GP30 Schematics, Layers and BOM Schematics, Layers and BOM Figure 31: GP30-DEMO MODULE Schematics Demo Kit Manual • PUBLIC UG000292 • v1-00 • 2019-Feb-26 │ 29...
  • Page 30 Assembly Figure 33: Bill of Materials for GP30 Demo Module Item Reference Value Part Desc Type TDC-GP30 QFN32 TDC-GP30 UFC ams 3.0 V XC6206 Voltage regulator 4 MHz CSTR_G Ceramic resonator Murata 32.768 kHz KX-327XS Quartz crystal Geyer 4.7 μF...
  • Page 31 Document Feedback TDC-GP30 Schematics, Layers and BOM Item Reference Value Part Desc Type 10 MΩ R805 Chip resistor 1 k Ω R805 Chip resistor 560 k Ω R805 Chip resistor 2.pol ST/254_2 Connector for power supply (combined with J22) 7.pol ST/254_7_1R Connector for SPI interface (combined with J13)

  • Page 32: Reference Modules And Transducers

    Reference Modules and Transducers Modules ams has a close cooperation with Qingdao iESLab to support customers with complete ultrasonic flow modules for water and gas. For water, iESLab offers pipes made of brass and made of plastic and modules can be ordered un-calibrated or calibrated. The gas meter modules are made of plastic and come un-calibrated, as the final housing will have a major impact on the calibration.
  • Page 33 Document Feedback TDC-GP30 Reference Modules and Transducers Figure 36: Measurement Characteristics Nominal Diameter [mm] Starting Flow [m³/h] 0.002 0.003 0.003 0.005 0.005 Minimum Flow Rate Q [m³/h] 0.010 0.016 0.025 0.040 0.064 Transitional Flow Rate Q [m³/h] 0.016 0.025 0.040 0.064 0.100 Permanent Flow Rate Q...
  • Page 34 Document Feedback TDC-GP30 Reference Modules and Transducers Figure 38: Ordering Information Ordering Code Description Part Number Markup Information Water meter module with plastic IA-UWM-3-GP30-DN20- pipeline t.b.d. IA-UWM-3-GP30-DN20 YYYYMMDD-SSSSSS No calibration Water meter module with plastic IA-UWM-4-GP30-DN20- pipeline t.b.d. IA-UWM-4-GP30-DN20 YYYYMMDD-SSSSSS With calibration YYYY = year, MM = month, DD = day, SSSSSS = product serial number that day Figure 39:...
  • Page 35 Document Feedback TDC-GP30 Reference Modules and Transducers Figure 40: Gas Meter Module, Brass Figure 41: Ordering Information Ordering Code Description Part Number Markup Information IA-UGM-1-YYYYMMDD- t.b.d. Gas meter module residential IA-UGM-1 SSSSSS Gas meter module industrial and IA-UGM-2-YYYYMMDD- t.b.d. IA-UGM-2 commercial SSSSSS YYYY = year, MM = month, DD = day, SSSSSS = product serial number that day...

  • Page 36: Transducers

    Document Feedback TDC-GP30 Reference Modules and Transducers Contact information: Qingdao iESLab Electronic Co., Ltd. High-tech Zone, Han Yu Valley Building A2-3 17 layers, Ningxia Road 288, Qingdao Software Park Building 3, Room 601, Qingdao, 266070, China http://en.qdies.com Mr. WANG Chuan Mobile: +86 177-5310-5044 Email: wangchuan@ieslab.cn...
  • Page 37 Document Feedback TDC-GP30 Reference Modules and Transducers Part Number Frequency Drawing PSC200K016191H2AD1-B1 200 ± 10 kHz 600 pF ± 20% -35 to 70 °C Angle > 6° (half angle) Water Meters 1.0 ± 0.1 MHz 100 to 350 Ω R1MHz 1300 pF ±...
  • Page 38 Document Feedback TDC-GP30 Reference Modules and Transducers Part Number Frequency Drawing 2.0 ± 0.1 MHz 150 to 500 Ω R1MHz 1100 pF ± 20% PSC2.0M018223H2AD2-B0 -40 to 85 °C >200mV (@ 3Vpp, 140mm) 4.0 ± 0.2 MHz 30 to 150 Ω R1MHz 2050 pF ±...

  • Page 39: Revision Information

    Document Feedback TDC-GP30 Revision Information Revision Information Changes from previous version to current revision v1-00 Page Section 7, Reference Modules and Transducers, added 31ff ● Page and figure numbers for the previous version may differ from page and figure numbers in the current revision. ●...

  • Page 40: Legal Information

    AG shall not be liable to recipient or any third party for any damages, including but not limited to personal injury, property damage, loss of profits, loss of use, interruption of business or indirect, special, incidental or consequential damages, of any kind, in connection with or arising out of the furnishing, performance or use of the technical data herein.
