12. INSTALLING THE LED LUMINAIRE MODULE (cont.)
5.
If installing the optional metal light cover, make sure it is securely
tightened. (Fig. 20)
NOTE: Add metal light cover if you do not need lighting function or prefer a
different aesthetic. (Fig. 20)
NOTE: Do not connect the LED connector wires if you are using the metal
light cover.
Metal light cover
FIGURE 20
F R-W 18 0 3
18
