- Page 1 Aviator Flush Installation Instructions works with the Google Assistant...
- Page 2 Please read and save these instructions before installation DO NOT RETURN TO STORE F H - W 1 8 1 1 Aviator Flush Instructions...
- Page 3 For fast service have the following information below when you call: Model Name and Number 2. Part Number and Part Description 3. Date Of Purchase and Purchase Location 1-866-810-6615 option 1 MON-FRI 8AM-8PM EST Email: customerservice@modernforms.com FH-W 1 8 1 1 Aviator Flush Instructions 3...
- Page 4 All set screws must be checked and re-tightened where necessary before installation. F H - W 1 8 1 1 Aviator Flush Instructions...
- Page 5 Modern Forms. Substitution of parts or accessories not designated for use with this product by Modern Forms could result in personal injury or property damage and will void the warranty. Contact an authorized dealer or the manufacturer if any parts are damaged or missing.
- Page 6 Dims light to 1% | ON/OFF personalize your experience 6 fan speeds F-RCBT-WT White Wi-Fi Touch Panel Wall Control Full app control | Sold separately F-TS-BK Black F-TS-WT White F H - W 1 8 1 1 Aviator Flush Instructions...
-
Page 7: Table Of Contents
6. Installing the Wall Control 7. Finishing the Installation 8. Installing the LED Luminaire Module 9. Controlling the Fan 10. Factory Reset 11. Breeze Mode 12. Application 13. Accessories Tools Required FH-W 1 8 1 1 Aviator Flush Instructions 7... - Page 8 Hanger Plate Before discarding packaging materials be certain all parts have been removed. Place the parts from the hardware bag into a small container to keep them from being lost. F H - W 1 8 1 1 Aviator Flush Instructions...
- Page 9 Hanging Weight: 13 lbs IMPORTANT: Please make note of the MAC ID on the receiver and keep it in a safe place. FH-W 1 8 1 1 Aviator Flush Instructions 9...
-
Page 10: Mounting Options
45° (Fig.3). NOTE: You may need a longer downrod to maintain proper blade clearance when installing on a steep, sloped ceiling (Fig. 3). F H - W 1 8 1 1 Aviator Flush Instructions... - Page 11 Support Brace Joist Outlet Box Outlet Box SLOPED CEILING Provides MAX 30° ANGLE Strong Support Mounting Recessed Outlet Box Bracket Outlet Box UL/cUL Mounting 120V Wir Mounting Mounting Screw Screws FH- W18 11 Aviator Flush Instructions 11...
-
Page 12: Installing The Mounting Bracket
3. Secure the bottom of the blades together using the provided blade collector ring and hardware (Fig. 3A). 4. Attaching Decorative Lower Cap Tightly twist the decorative lower cap onto the motor assembly (Fig. 4). F H - W 1 8 1 1 Aviator Flush Instructions... - Page 13 FH- W18 11 Aviator Flush Instructions 13...
-
Page 14: Making The Electrical Connections
Connect the black (hot) wire from the ceiling to the black wire marked “AC in L” from the receiver. 8. Connect the white (neutral) wire from the ceiling to the white wire marked “AC in N” from the receiver. F H - W 1 8 1 1 Aviator Flush Instructions... - Page 15 Follow the steps below to connect the fan to your household wiring. Use the plastic wire nuts with your fan. Secure the plastic wire nuts with electrical tape. Make sure there are no loose strands or connections. FH-W 1 8 1 1 Aviator Flush Instructions 15...
-
Page 16: Installing The Wall Control
(2) wall mounting plate screws provided (Fig. 4A). Fasten the wall plate to the wall mounting plate (Fig. 4A). White (Neutral) White White Black (to fan) Black (from Breaker) Black Copper Green (Ground) Ground F H - W 1 8 1 1 Aviator Flush Instructions... - Page 17 Maximum of 2 fans can operate on a circuit through the wall transmitter. Maximum of 12 fans can operate on a circuit through an on/off switch or breaker when utilizing the app for the fan control (without the wall control in the circuit). FH-W 1 8 1 1 Aviator Flush Instructions 17...
-
Page 18: Finishing The Installation
Make sure tab at bottom of hanger bracket is properly seated in groove of hanger ball before attaching canopy to bracket. Failure to properly seat tab in groove could cause damage to electrical wiring. F H - W 1 8 1 1 Aviator Flush Instructions... - Page 19 FH-W 1 8 1 1 Aviator Flush Instructions 19...
-
Page 20: Installing The Led Luminaire Module
Seat the LED luminaire onto LED mounting plate using 3 screws provided with LED luminaire (Fig 8C). Install glass shade by turning it clockwise until it locks securely (Fig. 8D). F H - W 1 8 1 1 Aviator Flush Instructions... - Page 21 FH-W 1 8 1 1 Aviator Flush Instructions 21...
-
Page 22: Controlling The Fan
To bring the fans/lights back into sync please follow the instructions on the next page. F H - W 1 8 1 1 Aviator Flush Instructions... - Page 23 All fans will be set to summer mode (CCW rotation). This will bring all fans controlled by the remote into sync. FH-W 1 8 1 1 Aviator Flush Instructions 23...
-
Page 24: Factory Reset
You will receive a prompt to name your fan device and upload an optional picture of it if you choose. The Modern Forms app will walk you through the main screen and show you how to create schedules, change fan speeds, dim the light, switch between Summer and Winter Modes, invite users, create groups and much more. - Page 25 Press and hold buttons for 10 seconds until the receiver beeps Scan and follow prompts for multilingual instruction options and Smart Fan FAQs: Spanish For detailed Instructions and Smart Home Device Integration French FH-W 1 8 1 1 Aviator Flush Instructions 25...
-
Page 26: Accessories
Included with each fan 6 fan speeds Dims light to 1% | ON/OFF F-WCBT-WT White Bluetooth Remote Control Dims light to 1% | ON/OFF 6 fan speeds F-RCBT-WT White F H - W 1 8 1 1 Aviator Flush Instructions... - Page 27 FH-W 1 8 1 1 Aviator Flush Instructions 27...
- Page 28 Notice of a defect in writing must be received by Modern Forms within five (5) years from the date of purchase (or according period of time as outlined by material). Excluded from warranty are any 3rd party component which carries its own manufacturer’s warranty.
- Page 29 La notificación de un defecto por escrito debe ser recibida por Modern Forms dentro de los cinco (5) años a partir de la fecha de compra (o según el período de tiempo indicado en el material). Quedan excluidos de la garantía todos los componentes de terceros que tengan la garantía de su propio fabricante.
