Parameters
12-02 Subnet Mask
Range:
Function:
[000.000.000.000 -
Configure the IP subnet mask of the
255.255.255.255]
option. Read-only if 12-00 IP Address
Assignment set to DHCP or BOOTP.
12-03 Default Gateway
Range:
Function:
[000.000.000.000 –
Configure the IP default gateway of
255.255.255.255]
the option. Read-only if 12-00 IP
Address Assignment set to DHCP or
BOOTP.
12-04 DHCP Server
Range:
[000.000.000.000 –
Read only. Displays the IP address
255.255.255.255]
of the found DHCP or BOOTP
server.
NOTICE
A power-cycle is necessary after setting the IP parameters
manually.
12-05 Lease Expires
Range:
Function:
Size related
[ 0 - 0 ] Read only. Displays the lease-time left for
*
the current DHCP-assigned IP address.
12-06 Name Servers
Range:
Function:
0
[0 - 2147483647 ] IP addresses of Domain Name Servers.
*
Can be automatically assigned when
using DHCP.
12-07 Domain Name
Range:
Function:
0
[0 - 2147483647 ] Domain name of the attached network.
Can be automatically assigned when
using DHCP network.
12-08 Host Name
Range:
Function:
Blank
[0-19 characters]
Logical (given) name of option.
12-09 Physical Address
Range:
Function:
0
[0 - 0 ] Read only. Displays the Physical (MAC) address of
*
the option.
MCA 122 Modbus TCP
Function:
®
MG90P202 - VLT
is a protected Danfoss trademark
5.2.2 12-1* Ethernet Link Parameters
Applies for whole parameter group.
Index [0] is used for Port 1 and Index [1] is used for Port 2.
For EtherCAT, Index [0] is for In Port and Index [1] is for
Out port.
12-10 Link Status
Option:
Function:
Read only. Displays the link status of the Ethernet
ports.
[0] No Link
[1] Link
12-11 Link Duration
Range:
Function:
Size related
[ 0 - 0 ] Read only. Displays the duration of the
*
present link on each port in dd:hh:mm:ss.
12-12 Auto Negotiation
Option: Function:
Configures Auto Negotiation of Ethernet link
parameters, for each port: ON or OFF.
[0] Off Link Speed and Link Duplex can be configured in
12-13 Link Speed and 12-14 Link Duplex.
[1] On
12-13 Link Speed
Option:
Function:
Forces the link speed for each port in 10 or 100
Mbps. If 12-12 Auto Negotiation is set to: [ON],
this parameter is read only and displays the
actual link speed. "None" is displayed if no link
is present.
[0]
None
*
[1]
10 Mbps
[2]
100 Mbps
12-14 Link Duplex
Option:
Function:
Forces the duplex for each port to Full or Half
duplex. If 12-12 Auto Negotiation is set to: [ON],
this parameter is read only.
[0] Half Duplex
[1] Full Duplex
NOTICE
In POWERLINK this parameter is locked to half duplex.
5
5
31
