Parameters
8-13 Configurable Status Word STW
Option: Function:
[71] Logic Rule 1 See parameter group 13-4* Logic Rules. If
Logic Rule 1 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
[72] Logic Rule 2 See parameter group 13-4* Logic Rules. If
Logic Rule 2 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
[73] Logic Rule 3 See parameter group 13-4* Logic Rules. If
Logic Rule 3 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
[74] Logic Rule 4 See parameter group 13-4* Logic Rules. If
Logic Rule 4 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
[75] Logic Rule 5 See parameter group 13-4* Logic Rules. If
Logic Rule 5 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
[80] SL Digital See 13-52 SL Controller Action. The output
Output A goes high whenever the Smart Logic
Action [38] Set digital out A high is
executed. The output goes low whenever
the Smart Logic Action [32] Set digital out
A low is executed.
[81] SL Digital See 13-52 SL Controller Action. The input
Output B goes high whenever the Smart Logic
Action [39] Set digital out B high is
executed. The input goes low whenever
the Smart Logic Action [33] Set digital out
B low is executed.
[82] SL Digital See 13-52 SL Controller Action. The input
Output C goes high whenever the Smart Logic
Action [40] Set digital out C high is
executed. The input goes low whenever
the Smart Logic Action [34] Set digital out
C low is executed.
[83] SL Digital See 13-52 SL Controller Action. The input
Output D goes high whenever the Smart Logic
Action [41] Set digital out D high is
executed. The input goes low whenever
the Smart Logic Action [35] Set digital out
D low is executed.
[84] SL Digital See 13-52 SL Controller Action. The input
Output E goes high whenever the Smart Logic
Action [42] Set digital out E high is
executed. The input goes low whenever
the Smart Logic Action [36] Set digital out
E low is executed.
[85] SL Digital See 13-52 SL Controller Action. The input
Output F goes high whenever the Smart Logic
Action [43] Set digital out F high is
executed. The input goes low whenever
the Smart Logic Action [37] Set digital out
F low is executed.
MCA 122 Modbus TCP
8-14 Configurable Control Word CTW
Option:
[0] None
[1] Profile default
[2] CTW Valid,
[3] Safe Option
[4] PID error
[5] PID reset I
[6] PID enable
8-50 Coasting Select
Option:
[0] Digital
[1] Bus
[2] Logic AND
[3] Logic OR
8-51 Quick Stop Select
Select control of the Quick Stop function via the terminals
(digital input) and/or via the bus.
Option:
[0]
[1]
[2]
[3]
®
MG90P202 - VLT is a protected Danfoss trademark
Function:
Selection of control word bit 10, if it is active
low or active high.
active low
Reset
When enabled, it inverts the resulting error
inverse from the process PID controller. Available
only if "Configuration Mode" is set to "Surface
Winder", "Extended PID Speed OL" or
"Extended PID Speed CL".
When enabled, resets the I-part of the Process
part PID controller. Equivalent to 7-40 Process PID
I-part Reset. Available only if "Configuration
Mode" is set to "Surface Winder", "Extended
PID Speed OL" or "Extended PID Speed CL".
When enabled, enables the extended process
PID controller. Equivalent to 7-50 Process PID
Extended PID. Available only if "Configuration
Mode" is set "Extended PID Speed OL" or
"Extended PID Speed CL".
Function:
Select control of the coasting function via the
terminals (digital input) and/or via the bus.
Activates Start command via a digital input.
input
Activates Start command via the serial
communication port or fieldbus option.
Activates Start command via the fieldbus/serial
communication port, AND additionally via one
of the digital inputs.
Activates Start command via the fieldbus/serial
communication port OR via one of the digital
inputs.
Digital input
Bus
Logic AND
Logic OR
5
Function:
