The Prodk Daughter Board; Figure 3: Main Board - Daughter Board Alignment; Figure 4: The Da14695 Daughter Board Layout - Dialog Semiconductor DA14695 ProDK User Manual

UM-B-090
DA1469x Getting Started Guide with the Development Kit
NOTE
J3 and J4 (Reference 8 in
power signals, with markings of signal names on the PCB top silkscreen.
NOTE
For current measurement circuit by SmartSnippets Toolbox (driven from a DA14695 GPIO, P0_16 ) you should
power the main board by the USB connector.
5.2

The ProDK daughter board

The ProDK main board can be combined with the daughter board shown in
Both ProDK main board and daughter board have alignment arrows printed to indicate the proper
combination of the two boards, as shown in
Figure 4 presents the DA14695 daughter board Layout.
User Manual
CFR0012
Figure 2
) are the Breakout Headers (2 pcs 2x20pin) for monitoring GPIO and
Figure

Figure 3: Main board - daughter board alignment

Figure 4: The DA14695 daughter board Layout
