Company Confidential
User Manual
DA14585 IoT Multi Sensor
Development Kit User Guide
UM-B-100

Abstract

IoT Multi Sensor Development Kit (MSK) based on DA14585 supports 15 Degrees of Freedom and
includes five reference designs: IoT Sensors, Smart Tag, and three different types of beacons. The
corresponding apps run on iOS/Android devices and the cloud services offers great flexibility to
customers in product design. This document describes the architecture and the implementation
details of DA14585 IoT MSK reference design and the supporting applications.
