User manual DA1468x Development kit - Basic UM-B-066 Abstract This document outlines the system design, configuration options and supported features of DA1468x Basic Development Kit, rev-E (224-18-E). -
Page 2: Table Of Contents
5.12 Leakage currents during power measurement ..............17 5.13 UART header (J13) ......................17 5.14 Power section ........................19 5.14.1 Battery options ..................... 20 Revision history .......................... 22 User manual Revision 1.4 26-March-2018 CFR0012 2 of 23 © 2018 Dialog Semiconductor... -
Page 3: Figures
Table 5: Signals using a voltage level translation/isolation chip ............17 Table 6: DA1468x pin assignment of UART signal ................18 Table 7: DA1468x SoC power options ....................19 User manual Revision 1.4 26-March-2018 CFR0012 3 of 23 © 2018 Dialog Semiconductor... -
Page 4: Terms And Definitions
Surface Mounted Device System on Chip Serial Peripheral Interface UART Universal Asynchronous Receiver/Transmitter Universal Serial Bus References DA14681 Datasheet, Dialog Semiconductor AN-B-041, DA14681 Development kit - Basic: UART with HW handshake, Application note, Dialog Semiconductor User manual Revision 1.4 26-March-2018 CFR0012 4 of 23 ©... -
Page 5: Introduction
DA14681 Basic: DA14681-00 Basic Kit / 224-18-E System overview Features ■ Highly integrated Dialog Semiconductor DA1468x SoC ■ DA1468x access over UART and/or JTAG without additional external hardware ■ Access on all GPIOs provided from the chip, when no sensor board is plugged in ■... -
Page 6: General Description
The Basic development kit is based on the DA1468x SoC in an aQFN60 package. The highlighted sections of the system are: 1. DA1468x Dialog Semiconductor processor and interfaces. 2. QSPI Flash memory (U9 or U2): only for DA14681 devices. 3. USB port (USB2) with mini-USB connector. This is the evaluation, power supply and debugging port of the development kit. -
Page 7: Figure 2 - Block Diagram Of Da1468X Basic Development Kit
Breakout headers Figure 2 - Block diagram of DA1468x Basic development kit The Basic development kit supports, DA14681 SoCs from Dialog Semiconductor. This is achieved by using the same board layout and populating different versions of the SoC. User manual Revision 1.4... -
Page 8: Basic Development Kit System
DA1468x Sensor board can be plugged directly on breakout headers J3, J4, J6. Power source selection: LDO with options for 1.8 V, 3.0 V (default) or 3.3 V (USB powered) CR2032 coin-cell battery User manual Revision 1.4 26-March-2018 CFR0012 8 of 23 © 2018 Dialog Semiconductor... -
Page 9: Da1468X System
V18, V18P: Power rails (1.8 V) for supplying external devices, even when the system is in sleep mode. Decoupling ceramic capacitors (C4, C5) of 10 F (0603 package, 16 V), are placed as close User manual Revision 1.4 26-March-2018 CFR0012 9 of 23 © 2018 Dialog Semiconductor... -
Page 10: Da1468X Pin Assignment
Option to connect to J4.19 (place R5) P2_1 XTAL32M Option to connect to J4.21 (place R6) P2_2 GPIO J6.4 P2_3 J3.19 P2_4 SWCLK J3.20 P3_0 GPIO J3.3 P3_1 GPIO J3.5 User manual Revision 1.4 26-March-2018 CFR0012 10 of 23 © 2018 Dialog Semiconductor... -
Page 11: Basic Development Kit Jumper Settings
P1_5 to LED D2. Remove jumper to use for RTS or other purpose. Mounted Mounted: P1_6 to K1 (button). Remove jumper to use for CTS or other purpose. User manual Revision 1.4 26-March-2018 CFR0012 11 of 23 © 2018 Dialog Semiconductor... -
Page 12: Booting From Uart
Accuracy ±20 ppm Load Capacitance (C 7 pF Shunt Capacitance (C 0.9 pF to 1.2 pF Equivalent Series Resistance (ESR) 70 kΩ 0.5 W Drive Level (P User manual Revision 1.4 26-March-2018 CFR0012 12 of 23 © 2018 Dialog Semiconductor... -
Page 13: Rf Port
Removing the plug restores the circuit back to its normal condition. Murata offers several options for a mating plug, MXHS83QH3000 is one possible pigtail option. Figure 5: RF port, printed antenna and RF switch User manual Revision 1.4 26-March-2018 CFR0012 13 of 23 © 2018 Dialog Semiconductor... -
Page 14: Qspi Data Flash Memory (U9 Or U2)
Termination resistors are placed between the processor and Flash memory. These resistors are not required, but they are placed there to mitigate any signal integrity issues when additional loads are present (e.g. logic analyser probes on the breakout headers). User manual Revision 1.4 26-March-2018 CFR0012 14 of 23 © 2018 Dialog Semiconductor... -
Page 15: Push Buttons And User Controlled Leds
D2 (Orange LED): driven from P1_5 through header J5. Please notice that via header J13, P1_5 is connected also to RTS. VBAT+ TP35 LED1 LED1 1.0uF LUW JLSH-5B8B-I4Q7-EG-LP WHITE LED Figure 8: White LED User manual Revision 1.4 26-March-2018 CFR0012 15 of 23 © 2018 Dialog Semiconductor... -
Page 16: Debugging Processor (U4)
Segger firmware and serial number. Headers J13 and J12, for UART and JTAG respectively, interconnect the debugging processor with the DA1468x processor. Figure 9: Debugging processor User manual Revision 1.4 26-March-2018 CFR0012 16 of 23 © 2018 Dialog Semiconductor... -
Page 17: 5.11 Voltage Level Translation
JTAG can be isolated from the rest of the (debugging) circuit by removing the jumpers from J13 and J12 for UART and JTAG respectively. 5.13 UART header (J13) J13 interconnects DA1468x SoC UART signals with U4, the debugging processor. User manual Revision 1.4 26-March-2018 CFR0012 17 of 23 © 2018 Dialog Semiconductor... -
Page 18: Figure 11: Uart Header (J13)
Please note that full handshake UART is not supported for booting. For more details, refer to application note AN-B-041 (Ref. [2]). Figure 12: Full UART hardware configuration User manual Revision 1.4 26-March-2018 CFR0012 18 of 23 © 2018 Dialog Semiconductor... -
Page 19: 5.14 Power Section
U5: This LDO can generate an output voltage of 3.3 V, 3.0 V or 1.8 V. For 1.8 V remove the jumper on header J9 (see Figure 14). By default the output voltage (VLDO) is 3.0 V. User manual Revision 1.4 26-March-2018 CFR0012 19 of 23 © 2018 Dialog Semiconductor... -
Page 20: Battery Options
VBAT. Please note that charging a rechargeable battery is not supported. Figure 15: Typical CR2032 (non-rechargeable) coin cell battery User manual Revision 1.4 26-March-2018 CFR0012 20 of 23 © 2018 Dialog Semiconductor... -
Page 21: Figure 16: Coin Cell Battery Placement
For battery replacement/removal, pull back the metallic clip (blue rectangle) and the battery will pop out by the spring of the battery holder (red rectangle). See. Figure 17. Figure 17: Removing the coin cell battery User manual Revision 1.4 26-March-2018 CFR0012 21 of 23 © 2018 Dialog Semiconductor... -
Page 22: Revision History
Revision history Revision Date Description 11-May-2016 Initial version. 26-May-2016 Improved pictures 10-June-2016 Updated to Rev.E 19-August-2016 Minor modifications to adapt to the DA1468x version 26-March-2018 Format changes User manual Revision 1.4 26-March-2018 CFR0012 22 of 23 © 2018 Dialog Semiconductor... -
Page 23: Um-B
Dialog Semiconductor excludes all liability in this respect. Customer notes that nothing in this document may be construed as a license for customer to use the Dialog Semiconductor prodCTS, software and applications referred to in this document. Such license must be separately sought by customer with Dialog Semiconductor.
