UM-B-090
DA1469x Getting Started Guide with the Development Kit

Table 2: DA14695 Daughter Board main elements

Reference Description
1 U1: DA14695 in micro-BGA package
2 USB connector, alternative power option and connecting to DA14695 USB pins
3 U2: QSPI Flash (MX25U3235F :32Mbit)
4 Printed RF antenna
5 J4: Debug
6 Power Select
7 Reset
8 Y1 : Cristal 32 Mhz
9 Y2 : Cristal 32.768 KHz
10 J7: Coaxial switch for conducted RF measurements
NOTE
The daughter board has a switch (reference 6 in The DA14695 daughter board Layout) to select the power
supply for the device:
•
Power switch pos1 (left-default): VBAT LDO (default, this is the only option where the current is monitored
by Studio - Toolbox)
•
Power switch pos2 (right): Battery, Li-Ion (default) or Coin Cell
NOTE
The daughter board has the possibility to operate stand-alone (without the main board), powered from one of
these options:
•
Li-Ion/LiPo/coin Battery
•
USB connector
•
CIB interface (providing also JTAG/UART debugging functions)
5.3

Configuring the Pro Kit main Board by Jumper Settings

The jumper settings are displayed below:
