UM-B-090
DA1469x Getting Started Guide with the Development Kit
•
4x More resources
The DA1469x SoCs combine :
•
The newest ARM Cortex application processor with floating point unit
•
Advanced power management functionality
•
A cryptographic security engine
•
Analog and digital peripherals
•
A dedicated sensor node controller
•
Software configurable protocol engine accompanied by a radio compliant to the Bluetooth® 5.0
low energy standard.
For further reading, more information can be found in the
4.1

Guide Purpose

The purpose of this guide is to provide an overview of the DA14695 Pro Development Kit (ProDK)
Board and describe the setup of the hardware and installation of the software tools to fully use the
board.
The following hardware and software elements are required to use the DA14695 Pro Development Kit:
•
The Pro Development Kit
•
SmartSnippets™ Studio 2.0 which can be installed on Windows or Linux hosts
•
Windows users should download and install terminal software such as RealTerm, Putty or
Teraterm. The rest of the document uses RealTerm. Linux users can use Putty
The rest of guide is organized as follows:
Section 5 describes the hardware components and their initial installation and setup.
describe the installation of the SmartSnippets™ DA14695 SDK software, along with
Sections 6 and 7
all necessary tools.
Section 9 contains all steps for downloading and executing your first DA14695 Application.
4.2

How long should it take?

This tutorial requires 45-60 minutes to complete. For more information the user may consult the
accompanied documentation these are mentioned as for further reading.
4.3

Kit Content

The DA14695 ProDK Kit parts can be ordered via various distributors. The DA14695 Pro Development
Kit contains the following:
•
DA14695-00HQDEVKT-P main Board:
•
Mini USB-cable
•
The DA14695-00HQDB-P daughter board
User Manual
CFR0012
and Software Development Kit (SDK)
Figure 2
Figure 4
Revision 1.0
6 of 46
DA1496x Datasheet .
