REFRIGERATION
9 SERIES
Rml9330, RML9331, RML9335
Absorber refrigerator
EN
Operating manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 9 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Dometic 9 Series

Summary of Contents for Dometic 9 Series

  • Page 1 REFRIGERATION 9 SERIES RML9330, RML9331, RML9335 Absorber refrigerator Operating manual...

  • Page 3: Table Of Contents

    RML93xx Please read this instruction manual carefully before first use, and store it in a safe place. If you pass on the product to another person, hand over this instruction manual along with it. Table of contents Explanation of symbols ......... . .4 Safety instructions .

  • Page 4: Safety Instructions

    Explanation of symbols RML93xx Explanation of symbols WARNING! Safety instruction: Failure to observe this instruction can cause fatal or serious injury. CAUTION! Safety instruction: Failure to observe this instruction can lead to injury. NOTICE! Failure to observe this instruction can cause material damage and impair the function of the product.
  • Page 5 RML93xx Safety instructions • This refrigerator can be used by children aged 8 years or over, as well as by persons with diminished physical, sensory or mental capacities or a lack of experience and knowledge, providing they are supervised or have been instructed how to use the refrigerator safely and are aware of the resulting risks.
  • Page 6 Safety instructions RML93xx Safe operation CAUTION! • Close the refrigerator door before beginning a journey. • The refrigerator unit at the back of the refrigerator gets very hot during operation. Protect yourself from coming into contact with hot parts when removing ventilation grilles. •...

  • Page 7: Scope Of Delivery

    RML93xx Scope of delivery Safety when operating with gas WARNING! • Only operate the refrigerator at the pressure shown on the type plate. Only use pressure controllers with a fixed setting which comply with the national regulations (in Europe EN 12864). •...

  • Page 8: Accessories

    Accessories RML93xx Accessories Available as accessories (not included in the scope of delivery): Description Fan kit for boosting the cooling capacity at high ambient temperatures Winter cover for the ventilation grille Door shelf locking Bottle holder for door shelf locking Shelf locking All the accessories are available from specialist dealers.

  • Page 9: Intended Use

    RML93xx Intended use Intended use The refrigerator is designed for installation in caravans or motorhomes. It is only suit- able for cooling, freezing and storing foodstuffs. The refrigerator is not intended for the proper storage of medicine. CAUTION! Health hazard! Please check if the cooling capacity of the refrigerator is suitable for storing the food you wish to cool.
  • Page 10 Technical description RML93xx Components No. in Description fig. 1 Control elements Freezer compartment Secondary evaporator for refrigerator Shelves Vegetable compartment Bottom section with bottle holder Top section...
  • Page 11 RML93xx Technical description Inside the refrigerator, you can see the type plate of the refrigerator. There you can see the model name, product number and serial number. You will need this information whenever you contact the customer service or order spare parts: MOD.

  • Page 12: Control Elements

    Technical description RML93xx Control elements The RML9330 refrigerator has the following control elements: RML 9330 No. in Description fig. 3 Power selector Temperature controller Battery igniter (gas) Pilot light...
  • Page 13 RML93xx Technical description The power selector (fig. 3 1) has the following setting options: RML 9330 No. in Description fig. 4 Operating with AC power supply Operating with DC power supply Gas operation...
  • Page 14 Technical description RML93xx The RML9331 and RML9335 refrigerators have the following illuminated control elements: RML 9331 / 9335 No. in Description fig. 5 ON/OFF button Operating with AC power supply Gas operation Operating with DC power supply Automatic mode (RML9335 only) Setting the temperature Temperature indication Malfunction indicator...

  • Page 15: Using The Refrigerator

    RML93xx Using the refrigerator Using the refrigerator NOTICE! • Make sure that you only put items in the refrigerator which may be kept at the selected temperature. • Food may only be stored in its original packaging or in suitable containers.
  • Page 16 Using the refrigerator RML93xx Switching on the refrigerator (RML9330) Operating with AC power supply ➤ Switch the refrigerator on by turning the power selector to the position. Operating with DC power supply NOTE Only select operation with DC power supply (battery mode) if the vehicle engine is running and providing sufficient voltage to the light system, or if you are using a battery monitor.
  • Page 17 RML93xx Using the refrigerator ➤ Press in the battery igniter as well and hold it down (B). ✓ The burner is ignited automatically. The needle of the pilot light moves to the green zone once the burner has ignited (C). ➤...
  • Page 18 Using the refrigerator RML93xx Automatic operation (RML9335 only) NOTE • To avoid unintentionally switching to gas operation while refuelling, the automatic mode starts the gas operation only once the engine has been off for 15 minutes. • Turn off the refrigerator or set it to a different operation mode, if refuelling lasts longer than 15 minutes.

  • Page 19: Selecting The Temperature

    RML93xx Using the refrigerator Selecting the temperature RML 9330 RML 9331 / 9335 NOTE • For ambient temperatures of +15 °C – +25 °C, select the centre position (fig. 7 1). The unit operates in the optimum power range. • In DC power mode, the refrigerator works without thermostatic control (permanent operation).
  • Page 20 Using the refrigerator RML93xx Notes on storing food CAUTION! Only store heavy objects such as bottles or cans in the refrigerator door, in the vegetable compartment or on the bottom shelf. The refrigerator compartments are recommended for the following types of food: No.

  • Page 21: Making Ice Cubes

    RML93xx Using the refrigerator Please observe the following instructions for storing items: NOTE • Do not keep carbonated drinks in the freezer compartment. • The freezer compartment is suitable for making ice cubes and for keeping frozen food short-term. It is not suitable for long-term food storage.
  • Page 22 Using the refrigerator RML93xx Setting up winter position Set up the winter position if you are not using the refrigerator for a longer period: ➤ Release the locking hooks of the door lock by pulling them out and folding them inwards (fig.
  • Page 23 RML93xx Using the refrigerator Using the optional battery compartment (RML9331 only) NOTICE! • Do not use different types of batteries. • Avoid short circuits at the contacts in the battery compartment. The optional battery compartment is located directly behind the control panel of the refrigerator (fig.
  • Page 24 Using the refrigerator RML93xx 7.10 Positioning the shelves WARNING! Children beware! The middle shelf is fixed to prevent children from climbing inside the refrigerator. • Only remove the middle shelf for cleaning purposes. • Replace it in the same position afterwards and lock it into place. Removing the shelf (fig.
  • Page 25 RML93xx Using the refrigerator 7.11 Removing/inserting the vegetable compartment Removing the vegetable compartment (fig. d) ➤ Open the refrigerator door to 90°. ➤ Pull out the vegetable compartment until the limit stop. ➤ Press in the limit stop on both the guide rails. ➤...
  • Page 26 Using the refrigerator RML93xx 7.12 Removing the freezer compartment Proceed as follows: ➤ Release the freezer compartment door with a screwdriver (A). ➤ Remove the freezer compartment door (B). ➤ Release the freezer compartment base on both sides (C). ➤ Remove the freezer compartment base (D). NOTE •...
  • Page 27 RML93xx Using the refrigerator 7.13 Defrosting the cooler NOTICE! Never use mechanical tools to remove ice or to loosen objects stuck to the device. NOTE Over time, frost builds up on the cooling fins inside the refrigerator. If this layer of frost is about 3 mm thick, you should defrost the refrigerator. ➤...
  • Page 28 Using the refrigerator RML93xx 7.14 Operating with low ambient temperatures NOTICE! Do not attach the top winter covers (not in scope of delivery) while oper- ating with gas. This prevents heat from building up and the fumes from the refrigerator can be extracted properly. NOTE •...
  • Page 29 RML93xx Using the refrigerator • LS230 ventilation grille:...
  • Page 30 Using the refrigerator RML93xx NOTE You recognise a mounted winter cover on the LS 230 ventilation grille by the bolts protruding from the ventilation grille (fig. h 1, page 29). 7.15 Replacing the batteries in the igniter (RML9330 only) 2 – 3 mm Proceed as follows: ➤...
  • Page 31 RML93xx Using the refrigerator 7.16 Replacing the door panel NOTICE! Beware of damage Only ever lay the refrigerator on its side and never on its back. Otherwise the unit may be damaged. Proceed as follows: ➤ Remove the door trim carefully. It is only stuck on and held by small hooks (A). ➤...

  • Page 32: Troubleshooting

    Troubleshooting RML93xx Troubleshooting Problem Possible cause Suggested remedy With AC operation: The fuse in the AC mains is Replace the fuse. The refrigerator does defective. not work. The vehicle is not connected Connect the vehicle to the to the AC mains. AC mains.
  • Page 33 RML93xx Troubleshooting Problem Possible cause Suggested remedy The refrigerator does The ventilation around the Check that the ventilation grille is not cool sufficiently. cooling unit is not sufficient. not obstructed. The evaporator is iced up. Check whether the refrigerator door is properly closed. Defrost the refrigerator.
  • Page 34 Troubleshooting RML93xx Displayed faults and signal tone (RML9331 and RML9335 only) Faults are indicated by the flashing of individual buttons on the control panel, a beep or a combination of both. Display Problem Suggested remedy With AC operation: The AC heating element Contact the authorised customer is defective.

  • Page 35: Cleaning And Maintenance

    RML93xx Cleaning and maintenance Display Problem Suggested remedy Beep is emitted for The interior light is Check whether the refrigerator 15 seconds at intervals of switched on. door is properly closed. two minutes Close the refrigerator door. Beep is emitted every The batteries in the bat- Replace the batteries in the battery 15 seconds...

  • Page 36: Maintenance

    Maintenance RML93xx ➤ Make sure that the ventilation grille in the outer wall of the caravan or mobile home (fig. g 1, page 28) and the roof vent (fig. k) of the refrigerator are free of any dust and dirt, so that heat generated during operation can be released and the refrigerator is not damaged.

  • Page 37: Warranty

    RML93xx Warranty Warranty The statutory warranty period applies. If the product is defective, please contact the manufacturer's branch in your country (see the back of the instruction manual for the addresses) or your retailer. For repair and guarantee processing, please include the following documents when you send in the device: •...

  • Page 38: Technical Data

    Technical data RML93xx Technical data RML9330 RML9331 RML9335 Voltage: 230 Vw / 50 Hz 12 Vg Gross capacity: 134 l Freezer compartment: 12 l Gross capacity 138.5 l (excluding freezer compart- ment): Net capacity: 129 l Net capacity 133.5 l (excluding freezer compart- ment): Power consumption:...
  • Page 39 RML93xx Technical data RML9330 RML9331 RML9335 Dimensions H x W x D: 420 mm 586,5 mm Weight: 37 kg Inspection/certification: NOTE You can obtain the CE declaration of conformity at Dometic.
  • Page 40 Dometic (Pty) Ltd. Dometic Branch Office Belgium MEXICO Regional Office Zincstraat 3 Dometic Mx, S. de R. L. de C. V. South Africa & Sub-Saharan Africa B-1500 Halle Circuito Médicos No. 6 Local 1 Unit 6-7 on Mastiff Linbro Park ...
