OptoTest OP415 Instruction Manual page 16

OP415
Front Panel Operation
Create Type Screen (cont.)
Unlike the Test screen, the lines on this screen
and the top row of numbers
row . A 0 in the top row indicates there is no connection.
3
Note: The top row of numbers
2
3
Although a scan is the easiest way to create a new type, it is possible to manually create
a type by using the edit functions on this screen. You should select a type from the folder
icon which is closest to the type you are going to edit.
Note: If edits are done instead of a Scan, the power reference values for this type
cable are not valid. You must use the reference screen found in page 2 of the settings
(see page 17) to update the references.
1
2 will indicate the connection to the source in the bottom
will change when you change the destination.
2
15 of 29
will always be straight up and down,
1
