- Page 1 MOBILE VIDEO RECORDER Quick Manual...
-
Page 2: Package Contents
How to install the product The appearance of the components may differ from the image shown. The images below are based on the TRM-1610S model. Accessory category and quantity may differ depending on sales region. Remove the mounting bracket and side brackets. -
Page 3: Installing The Hdd
Unscrew the HDD bracket fixing screws on the front of the set and pull it to the front to separate the HDD. The images below are based on the TRM-1610S model. If the lock on the front is locked, open the lock using the key that was provided when you purchased the product. -
Page 4: Install Wizard
Install Wizard Select the language Select your preferred language. Set Password Set a password. Set Date & Time Set the time and date and click the <Finish> button, and the installation will be completed. Camera Registration In the setting completion window, click on the <OK> button to finish camera setting and launch the camera registration screen. - Page 5 Configure and run layout Search You can use the same layout set on the live screen for the Search Time function in order to perform a search using the channel sequence and combination configured by the user. For more information about the detailed setting method for each stage, refer to the user manual. Live channel layout settings a The initial search option is set to <All Channels>.
- Page 6 Right-click on the live screen and you can access various functions that NVR provides. Hover over an icon and a brief definition of term for each function is prompted. Layout RES : 1920x1080 (H.264) SET/IN/DEC : 30/30/30.0 XXX-0000(S) Layout Setup TRM-1 TRM-1 Keep ch. scr ratio TRM-1610S Status TRM-1610S http://hanwha-security.com TRM-1610S TRM-1610S ZOOM TRM-1610S TRM-1610S Audio ...
- Page 7 FCC Compliance Statement This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.
- Page 8 Head Office 6, Pangyo-ro 319 beon-gil, Bundang-gu, Seongnam-si, Gyeonggi-do, 463-400 Rep. of KOREA Tel : +82.70.7147.8753 Fax : +82.31.8018.3740 http://hanwha-security.com Hanwha Techwin America 500 Frank W. Burr Blvd. Suite 43 Teaneck, NJ 07666 Toll Free : +1.877.213.1222 Direct : +1.201.325.6920 Fax : +1.201.373.0124 www.hanwhasecurity.com Hanwha Techwin Europe...
