- Page 1 DIGITAL VIDEO RECORDER Product Specification Manual ARD-1610 ARD-810 ARD-410...
- Page 2 Digital Video Recorder Product Specification Manual Copyright ©2022 Hanwha Techwin Co., Ltd. All rights reserved. Trademark Each of trademarks herein is registered. The name of this product and other trademarks mentioned in this manual are the registered trademark of their respective company. Restriction Copyright of this document is reserved.
-
Page 3: Important Safety Instructions
overview ImPorTanT SafeTY InSTrucTIonS Before STarT Read these operating instructions carefully before using the unit. This manual provides operational information necessary for using the product and contains a description about each Follow all the safety instructions listed below. component part and its function as well as menu or network settings. Keep these operating instructions handy for future reference. - Page 4 Function Products ● Ne pas ingérer la pile, risque de brûlure chimique. ARD-1610/ARD-810/ARD-410 ● Ce produit contient une pile de type bouton/pièce de monnaie. Si la pile de type bouton/pièce de monnaie ARD-1610/ARD-810/ARD-410 est avalée, elle peut causer de graves brûlures internes en seulement 2 heures et peut entraîner la mort.
-
Page 5: Table Of Contents
overview conTenTS overvIeW Important Safety Instructions Before Start Contents Features Package Contents Part Names and Functions (Front) Part Names and Functions (Rear) InSTallaTIon Checking the Installation Environment Rack Installation Power HDD Addition connecTIng WITH oTHer DevIce Connecting to an External Device Connecting the USB Connecting the Alarm Input/Output Connecting the Network... -
Page 6: Features
Remote monitoring function by Windows Network Viewer ● Live monitoring of the camera ● Installation Wizard Function (Recorder, Web Viewer) ● Supports the remote monitoring feature by DDNS/P2P support (Wisenet Viewer/Wisenet mobile) ● Provides smartphone event alarm (sending real-time event messages) 6_ overview... -
Page 7: Part Names And Functions (Front)
LED Indicator NETWORK(LAN) : Displays both network connection and data transfer status. BACKUP : The LED will light up when the Export Recorded Video is in operation. (N/A on ARD-810/ARD-410) POWER : Shows the power ON/OFF status. Connects the USB devices. (USB 2.0 supported) -
Page 8: Part Names And Functions (Rear)
BNC type of output port for the Spot signal. VGA OUT VGA video signal output port. ● ALARM IN : Alarm input ports. (1~4 CH) ALARM arD-810 ● ALARM OUT : Alarm output ports. (1 CH) RS485 Used to establish RS-485 communications. (TX+, TX-) AUDIO OUT Audio signal output port. -
Page 9: Checking The Installation Environment
installation Please take note of the followings before using this product. rack InSTallaTIon ● Do not use the product outdoor. Install the Bracket-Rack as shown in the figure, and then fasten the screws ● Do not spill water or liquid in the connection part of the product. on both sides. -
Page 10: Hdd Addition
Number of HDDs supported – ARD-1610 : Max. 2 EA How to install an HDD in arD-1610 – ARD-810 : Max. 1 EA 1. Loosen the screws on the left/right sides and back and slide the – ARD-410 : Max. 1 EA cover back to remove it. - Page 11 How to install an HDD in arD-810/arD-410 1. Loosen the screws on the back and slide the cover back to remove it. 2. Connect the SATA/power cable of the HDD to the connector on the motherboard. 3. Fix the HDD to the bottom of the recorder with screws.
-
Page 12: Connecting To An External Device
connecting with other device connecTIng To an exTernal DevIce connecTIng THe alarm InPuT/ouTPuT ■ The following figures are based on Model ARD-1610. The Alarm In/Out port at the back is composed of the following. Sensors Alarm 30VDC 2A, 125VAC 0.5A MAX MAX DC18V, Typical DC12V, 2A ●... -
Page 13: Connecting The Network
connecting with other device connecTIng THe neTWork connecting the network cameras ■ example) For more information about network connection, see “Setting the Network" in the User Manual. ex) IP : 192.168.1.100 network connection via ethernet (10/100/1000BaseT ) Switch Switch Windows Network Viewer Network Camera Network Camera... - Page 14 connecting with other device connecting the rS-485 Device Connect [TX/RX +,-] port on the rear to PTZ camera or system keyboard. TX + - TX + - Data + - PTZ Camera System keyboard ■ You can connect and control the PTZ camera which supports the RS-485 communication. ■...
