  • Page 1 AB900 AirBike OWNER’S MANUAL...

  • Page 3: Table Of Contents

    Exploded Diagram Parts List ® Copyright 2018. Spirit Fitness by Dyaco International. All rights reserved, including those to reproduce this book or parts thereof in any form without first obtaining written permission from Spirit Fitness. Every effort has been made to keep this information current; however, periodically, changes are made to the information herein, and these changes will be incorporated into new editions of this publication.

  • Page 4: Introduction

    This manual will acquaint you with the assembly, operation and maintenance of your Air Bike. • 900 Series – Air Bike manufactured by Spirit Fitness ® Be sure to read and follow the information and instructions before assembling, using or servicing your Air Bike.

  • Page 5: Warranty

    Spirit Fitness warrants all its fitness bike parts for a period of time listed below from the date of retail sale, as determined by sale receipt, or in the absence of a sales receipt eighteen (18) months from the original factory shipping date. Spirit Fitness’ responsibilities include providing new or remanufactured parts, at Spirit Fitness’...

  • Page 6: Customer Support

    • Spirit Fitness’ obligation under this warranty is limited to repairing or replacing, at Spirit Fitness’ option, the product through one of our authorized service centers. All repairs must be preauthorized by Spirit Fitness. If the product is shipped to a service center freight charges to and from the service center will be the customer’s responsibility.

  • Page 7: Precautions

    These safety notes are directed to you as the owner of the Air Bike manufactured by Spirit Fitness. Please train all your users and fitness staff to follow these safety instructions. • Do encourage each of your users to discuss their health program or fitness regimen with a healthcare professional.
  • Page 8 VOORZORGSMAATREGELEN Deze veiligheidsaantekeningen zijn aan u gericht als eigenaar van de Air Bike manufactured by Spirit Fitness. Gelieve uw gebruikers en uw per- soneel voor conditietraining volledig bekend te maken met deze veiligheidsinstructies. Doe het volgende: • Moedig elk van uw gebruikers aan hun gezondheidspro- gramma of conditietherapie met een professioneel uit de gezondheidszorg te bespreken.
  • Page 9 PRÉCAUTIONS Ces consignes de sécurités s'adressent aux propriétaires du Air Bike manufactured by Spirit Fitness. Veuillez instruire tous vos utilisateurs et instructeurs à suivre ces consignes. À Faire • Encouragez tous les utilisateurs à consulter un médecin au sujet de leur programme de fitness ou régime d'exercice.
  • Page 10 VORSICHTSMASSNAHMEN Die folgenden Vorsichtsmaßnahmen richten sich an Sie als Besitzer des Air Bike manufactured by Spirit Fitness. Bitte schulen Sie alle Ihre. Benutzer und Ihr Fitness-Personal in der Beachtung dieser Sicherheitsvorschrifte Gebote • Legen Sie jedem Ihrer Benutzer nahe, sein Gesundheits- oder Fitnessprogramm mit einem medi- zinischen Fachmann zu besprechen.
  • Page 11 Non cercate di rimuovere le coperture o di modificare lo bike. AVVERTENZE • Lo Air Bike manufactured by Spirit Fitness è stato realizzato per esercizi di aerobica in un ambiente pubblico o privato adeguato. • Prima di iniziare un programma di esercizio fisico, consultate il vostro medico.
  • Page 12 PRECAUÇÕES Estas notas de segurança destinam-se a você, proprietário do bike Air Bike manufactured by Spirit Fitness. Treine todos os usuários e o pessoal da academia para que sigam estas instruções de segurança. O que fazer • Incentive todos os usuários a discutirem seu programa de saúde ou sistema de condicionamento físico com um profissional da área de saúde.
  • Page 13 PRECAUCIONES Estas notas de seguridad están dirigidas a usted como el dueño de Air Bike manufactured by Spirit Fitness. Por favor instruya a todos sus usuar- ios y personal de entrenamiento para que sigan estas instrucciones de seguridad. Lo que se debe hacer •...
  • Page 14 FÖRSIKTIGHETSÅTGÄRDER Dessa säkerhetsanmärkningar är riktade till dig i egenskap av ägare av Air Bike manufactured by Spirit Fitness. Var god utbilda alla användare och all personal att följa dessa säkerhetsanvisningar. Man ska • Uppmuntra alla användare att konsultera sitt hälso- progam eller sin träningsregim med en läkare.
  • Page 15 注意事項 下述安全說明適用於您所擁有的由 Spirit Fitness 製造之風扇健身車。請培訓所有使用者與健身人員遵守下述安全說明。 遵守事項 • 鼓勵您的每個使用者在使用此健身車前，與專業的醫療保健專業人員討論他們的健康計劃或健身方案。 • 如果您感到頭暈或虛弱，請停止使用此健身車。 • 請定期進行預防性維護。 • 請緩慢且循序漸進使用此健身車，直至達到舒適程度。 禁止事項 • 請勿讓無人監管的兒童操作此健身車。 • 請勿在沒有穿著合適的運動鞋的狀況下使用此健身車。 • 請勿在戶外陰雨天氣或封閉的泳池環境中使用此健身車。 • 請勿讓任何物體、手或腳掉入或插入任何開口或飛輪區域內。 • 請勿嘗試拆除任何鏈蓋或修改健身車。 警告 • 您所擁有的由Spirit Fitness製造之風扇健身車，專為商業或消費環境中的有氧運動而設計。 • 在開始任何鍛煉計劃之前，請諮詢您的醫生。 • 請勿讓自己運動過量。 如果你感到昏厥，頭暈或疲憊，請停止使用。 使用此健身車時要運用一般常識。 • 在使用此健身車之前，請完整閱讀使用者手冊。 • 不遵守上述警告可能導致人身傷害或死亡。...
  • Page 16 奨励します。 • 使用前、使用中にめまいや気分が悪いと感じた場合は、直ちにバイクの使用をやめてエクササイズを中止してくださ い。 • エクササイズバイクの定期的な予防メンテナンスを行ってください。 • 行っているエクササイズが快適に感じるまではゆっくりと運動してください。 DO NOT（行わないでください） • 監督なしでの子供の自転車使用を禁止してください。 • 適切な運動靴なしで使用しないでください。 • 雨天時の屋外や屋内プールでの使用は避けてください。 • フライホイールの開口部やその付近に物、手、足、指等を落としたり、入れたり、触れたりしないようにしてください。 • カバーや覆いを取り外したり、このエクササイズバイクを改造しないでください。 警告 • この Air Bike は Spirit Fitness 社によって製造された、業務使用目的または個人使用目的の有酸素運動用に設計され たエクササイズバイクです。 • エクササイズプログラムを始める前に必ず医師にユーザー自身の健康状態を相談してください。 • 自分自身のレベルを超えた過度なエクササイズは避けてください。わずかでも、体調不良やめまいを感じたり、疲労を 感じた場合は直ちにエクササイズを中止して、使用を止めてください。エクササイズバイクの使用には適切な常識を適 用する事をお勧めいたします。 • エクササイズバイクを使用する前に、取扱説明書すべてを読み理解してください。 • この警告に従わない場合は、重篤な事故、怪我や死亡に繋がる可能性があります。...

  • Page 17: Warning Labels And Stickers

    Warning Labels and Communication Stickers ® The following pages show examples of Spirit Fitness warning labels and communication stickers placed on the equipment as part of the manufacturing process. It is critical that owners maintain the integrity and placement of these stickers. If you find any stickers missing or damaged contact your local dealer or distributor for a replacement.

  • Page 18: Safeguards

    afeguards NCTIONS The following fitness safeguards and operating precautions are directed to purchasers and users of the Air Bike. Club Managers should ensure that members and fitness staff are trained to follow these same instructions. Failure to follow these safeguards may result in injury or serious health risk.

  • Page 19: Assembly And Setup

    CAUTION: Damage to the bike during assembly is not covered as part of the limited Spirit Fitness warranty. Take care not to drop or lean the bike on its side. Carefully stand the bike up in the normal upright position on a stable surface so it will not tip over during assembly.

  • Page 20: Assembly Instructions

    STEP 1. Assembly of Front/Rear Stabilizers Use a wrench (100) to fasten the front stabilizer (2) onto the main frame (1) with two sets of hex head bolts (84) and flat washers (71). Use a wrench(100) to fasten the rear stabilizer (5) onto the main frame (1) with two sets of carriage bolts (50), flat washers (71), and cap nuts (135).
  • Page 21 STEP 2. Assembly of the console base Insert the cable (23) through the hole of the console base (10) carefully. Use a screw driver (93) to fasten the console base (10) onto the main frame (1) with three phillips head screws (90). HARDWARE #90.
  • Page 22 STEP 3. Assembly of Left/Right handlebars Insert one star washer (148) on the left handlebar (3) and right handlebar (4) before fasten them onto the main frame (1) with a wrench (95). Attach the left handlebar (3) and right handlebar (4) with Rocker links (8) on both sides of the main frame with two sets of bolts (136), rod end bearings (64), flat washers (81), nyloc nuts (75).
  • Page 23 STEP 4. Assembly of Console set, Seat, Pedals, and Connecting Arm Coves Connect the cable (23) to the console set (34) carefully. Use a screw driver (93) to fasten the console set (34) onto the console base (10) with four screws (58). Use a wrench (100) to fasten the left pedal (45L) onto the left crank arm (16L) and right pedal (45R) onto the right crank arm (16R) respectively.

  • Page 24: Testing Bike

    esting Use this checklist to perform the bike test procedure.  Recheck all the bolts and make sure they are all tightened to the proper torque specification (if indicated) and no parts are missing.  Test the seat post to make sure they move freely and you are able to lock in at different positions. ...

  • Page 25: Instructions

    Instructions Your Air Bike is easy to use. There are no resistance knobs to adjust as the resistance comes from the isokenetic resistance created by the movement of air with the fan-shaped flywheel. Control over the resistance is obtained by simply varying the pace of pedaling and of the push / pull on the movement arms.

  • Page 26: Training Information

    RAINING NFORMATION Before Beginning Be sure the seat is adjusted for your body size and comfort before beginning your workout. Consult your physician before beginning this or any other exercise routine. Discontinue any exercise that causes you discomfort and consult a medical expert. Warm-Up Once you are in position and sitting on the bike with your hands in a comfortable position on the movement arms, slowly begin pedaling, while pushing / pulling on the arms.

  • Page 27: Console Operation

    Console Operation CONSOLE KEYS Interval Display Panel Quick Mode Keys Quick Mode Keys Time, Distance, Calories, Watts, Speed, RPM Display Panel Bluetooth Key Hear Rate Display Panel Control Keypad...

  • Page 28: Console Keys

    CONSOLE KEYS The Quick Mode Keys will into the associated Mode immediately The ▲/▼ arrow keys allow the user to increase or decrease console values Use the Bluetooth key to upload the workout summary to APP. The START key will into a Use the STOP key to end mode;...
  • Page 29 Interval Display Panel The Interval Display Panel will show all details for the Interval 20/10, Interval 10/20 and Interval Custom mode. In upper banner will tell which interval mode is operating. This display will instruct whether the current operating interval is in WORK or REST period. The TOTAL TIME launch will show the total run time while the large numeric display will show the WORK or REST segment time.

  • Page 30: Programming

    Console Setup Battery Installation The console operates on 4*AA batteries (not included). The battery compartment is on the back side of the console. Setting Metric & Imperial Units – Setup Mode The default setting is in Imperial Units (mph). In the Ready Mode press and hold the START and ENTER keys for two (2) seconds until KM or M is flashing, pressing ▲ or ▼ to select metric (KM) or imperial (M) units, and then press ENTER to confirm.

  • Page 31: Console Programs

    Console Programs Quick Start The Quick Start Mode automatically begins displaying workout information as soon as pedalling begins. No programs run during Quick Start. The console will show up all data, including Heart Rate (if a heart rate chect strap is detected). Quick Start will end once pedalling is stopped.
  • Page 32 Target Heart Rate Mode The Target Heart Rate Mode allows the maximum beats per minute (BPM) target to be customized to maximize cardiovascular training, according to the user’s age The Heart Rate Mode calculates the maximum heart rate value to optimize the training target between 65% - 85% of users calculated or theoretical maximum heart rate .

  • Page 33: Engineering Mode

    Engineering Mode Press START and ENTER keys for 2 seconds to enter Engineering Mode. The console will also beep for 1 second. DISTANCE banner will blink first. Press UP or DOWN to select setting section. ( DISTANCE→Sound→odo→DISTANCE) While in Engineering Mode if there is no activity for 30 seconds, the console will switch STANDBY Mode. Pressing the RESET key twice will exit the Engineering Mode.

  • Page 34: Maintenance

    Working on this product will require basic and/or sometimes specialty tools based on the type of service that will be performed at any time. To assist, Spirit Fitness recommends having the tools listed (Fig. 1) available when performing maintenance. Tool...

  • Page 35: Weekly Maintenance

    Wipe Down / Cleaning To prevent the build-up of rust and other forms of corrosion, wipe down the bike at the end of each day (or preferably at the end of each class). Raise all posts to the highest setting to expose moisture. Using an absorbent cloth, focus on all areas that perspiration can settle.

  • Page 36: Frame Care

    • Tighten seat hardware. • Leveling feet. Frame Care It is recommended that the frame on the bike is sealed from sweat impurities that may speed the corrosion process at least once a month. Cleaning Using a clean terry cloth that is dampened in 30 parts water to 1 part non-abrasive detergent or car wash soap rub over the frame of the product.

  • Page 37: Exploded Diagram

    Exploded Diagram...

  • Page 38: Parts List

    Parts List DESCRIPTION Q'TY Main Frame Front Stabilizer Seat Handle Bar (L) Seat Handle Bar (R) Rear Stabilizer Seat Slider Sliding Seat Mount Rocker link Console Support Crank Axle Chainring Crank Arm Chain Joint(100) Chain Joint(68) Crank Arm(L) Crank Arm(R) Chainring gear Seat...
  • Page 39 DESCRIPTION Q'TY Arm fixed iron core M5 × 12m/m_Phillips Head Screw Adjustment Foot 6203_Bearing 6004_Bearing 6003_Bearing Rod End Bearing Fan Net (L) Fan Net (R) C Ring(40x1.85T) Ø20_C Ring Ø17 × Ø23.5 × 1T_Flat Washer Ø17 × Ø28 × 2T_Flat Washer M5 ×...
  • Page 40 DESCRIPTION Q'TY Ø8 × Ø25 × 5T_Nylon Washer 5 × 19m/m_Tapping Screw Rubber Pad Iron Net Wind Cover Connecting Arm Cover (R) Connecting Arm Cover (L) Ø6_Nut Stopper M6 × 40L_Idle Wheel Screw Ø16.7 × 2.5T_Star Washer...
  • Page 42 AB900 AirBike Owner’s Manual © 2018 All Rights Reserved Revision: 09.25.2018...
