Kraus Artec Pro KPF-1603 Installation Manual

Single handle commercial kitchen faucet
Hide thumbs

Advertisement

INSTALLATION GUIDE
Artec Pro
Single Handle Commercial
Kitchen Faucet
KPF-1603
www.kraususa.com I Toll Free: 1.800.775.0703 I © 2018 Kraus USA Inc. I REV. Aug 21, 2018

Advertisement

loading

  Also See for Kraus Artec Pro KPF-1603

  Related Manuals for Kraus Artec Pro KPF-1603

  Summary of Contents for Kraus Artec Pro KPF-1603

  • Page 1 INSTALLATION GUIDE Artec Pro Single Handle Commercial ™ Kitchen Faucet KPF-1603 www.kraususa.com I Toll Free: 1.800.775.0703 I © 2018 Kraus USA Inc. I REV. Aug 21, 2018...
  • Page 2 Congratulations on the purchase of your new Please keep the box and packaging materials until your product is completely installed. If you have any questions, require technical assistance, or have any problems with your product: DO NOT RETURN TO STORE Please contact our Customer Service Team 1-800-775-0703 / customerservice@kraususa.com Have the model number available, and retain a copy of your receipt...
  • Page 3: Prior To Installation

    Prior to Installation: • Make sure you have all necessary parts by checking the diagram and parts list. If any part is missing or damaged, please contact Kraus Customer Service at 800-775- 0703 for a replacement • to release any built-up pressure •...
  • Page 4 Diagram and Parts List A. Faucet Body B4. Mounting Nut B1. Seat B5. Screw B2. Rubber Washer C. 2.2 GPM Flow Restrictor B3. Metal Washer D. Hex Wrench...
  • Page 5 Faucet Dimension 7 5/8in [198.2mm] 9 3/4in [248.2mm] 4 1/8in 7 1/8in [106.5mm] [182.6mm] 24 3/4in [628.7mm] [153.2mm] 6 5/8in [173.3mm] 2 3/8in MAX:2 3/8in [60.8mm] [60.0mm] 9/16-24UNEF-2B Installer Tip:...
  • Page 6 Step 1: Remove washer and lock nut Shut o the water supply. Remove the old faucet. Clean the mounting surface. Remove mounting hardware (B) from faucet body (A). Step 2: Install faucet Insert faucet through hole in sink or countertop.From underneath sink, attach the seat (B1), rubber washer (B2), metal washer (B3), and nut (B4).
  • Page 7 Step 3: Making the water supply connections Push the quick connector (2) rmly upward andattach it to the receiving block (1). Pull down moderately to ensure the connection has been made. If it is necessary to remove the quick connector (2), squeeze the tabs on the hose and then pull down to disconnect.
  • Page 8 Step 5: Flushing and checking for leaks Pull the hose assembly out of the spout and remove the spray head by unscrewing it from the hose in a counterclockwise direction. Be sure to hold the end of the hose down into the sink and turn the faucet on to the warm position where it mixes hot and cold water.
  • Page 9 Please note that doing so will remove the capability of this product to meet speci c low- ow standards. Kraus is not liable for any alterations made to the product post-sale, and highly advises that you consult with your local or...
  • Page 10: Replacement Parts

    Replacement Parts Replacement Parts List Finish Part NO 1. Spray head CH, SFS, SFSMB KP27060 2. Magnet KP27061 BLBG, BLSFS, 3. Spray hose assembly KP27062 GRCH, GRSFS* 4. Spring CH, SFS, BG KP27063 5. Inverter KP27080 7 5/8” KP27064 6. Spray support assembly CH, SFS, BG KP27065 7.
  • Page 11: Troubleshooting

    Trouble - Shooting If you have followed the instructions carefully and your faucet still does not work properly, take the following corrective steps: P R O B L E M C A U S E A C T I O N Leakage under the Bonnet nut (12) has Remove the index (14.3).
  • Page 12 Any product reported to the authorized dealer or to Kraus as being defective within the warranty period will be repaired or replaced with a product of equal value at the option of Kraus. This warranty extends to the original owner or repaired or replaced with a product of equal value at the option of Kraus.
  • Page 13 Commercial Warranty Kraus extends the above warranty for a period of one (1) year to purchasers of products for industrial, commercial, and Kraus extends the above warranty for a period of one (1) year to purchasers of products for industrial, commercial, and business use.
  • Page 14 IMPORTANT Register Your Kraus Product Activate Your Warranty Access Premium Customer Support Get Product Information REGISTER TODAY http://www.kraususa.com/registration www.kraususa.com...
