USB-TEMP User's Guide
The USB-TEMP has four current excitation outputs, with ±I1 dedicated to the CH0/CH1
Note 18:
analog inputs, ±I2 dedicated to CH2/CH3, ±I3 dedicated to CH4/CH5, and ±I4 dedicated
to CH6/CH7. The excitation output currents should always be used in this dedicated
configuration.
The current excitation outputs are automatically configured based on the sensor
Note 19:
(thermistor or RTD) selected.

Environmental

Operating temperature range
Storage temperature range
Humidity

Mechanical

Dimensions
User connection length

Screw terminal connector type and pin out

Connector type
Wire gauge range
Table 5-17. Environmental specifications
0 to 70 ° C
-40 to 85 ° C
0 to 90% non-condensing
Table 5-18. Mechanical specifications
127 mm (L) x 88.9 mm (W) x 35.56 (H)
3 meters max.
Table 5-19. Screw terminal connector specifications
Screw terminal
16 AWG to 30 AWG
5-8
Specifications
