USB-7204 User's Guide

General

Parameter
Device type
Device compatibility
DEFAULTS for
programmable options and
"DEV:RESET/DEFAULT"
message

Environmental

Parameter
Operating temperature range
Storage temperature range
Humidity

Mechanical

Parameter
Dimensions (L × W × H)
USB cable length
User connection length

Screw terminal connector and pinout

Parameter
Connector type
Wire gauge range
Table 19. General specifications
Specification
USB 2.0 (full-speed)
USB 1.1, USB 2.0
AI Channel Mode = Differential
Range = ±10 V
AInScan Low Channel = 0
High Channel = 0
Samples = 1000
Rate = 1000
Range = ±10 V
Pacer = Master
Transfer Mode = BlockIO
Trigger = Disabled
Queue = Disabled
Status = Idle
AITrig Trigger Polarity = Rising
Rearm – Disabled
AOutScan Low Channel = 0
High Channel = 0
Samples = 1000
Rate = 1000
Trigger = Disabled
Status = Idle
CTR Value = 0
Table 20. Environmental specifications
Specification
0 °C to 70 °C
–40 °C to 70 °C
0% to 90% non-condensing
Table 21. Mechanical specifications
Specification
90.17 × 95.25 × 12.70 mm (3.55 × 3.75 × 0.5 in.)
111.76 mm (4.40 in.) length with detachable screw terminals connected
3 m (9.84 ft) max
3 m (9.84 ft) max
Table 22. Connector specifications
Specification
Screw terminal
16 AWG to 30 AWG
27
Specifications
