WebDAQ 504 User's Guide

Power

Parameter
Input voltage
Input wattage
External power adapter
Battery

Mechanical

Parameter
Dimensions (L × W × H)
Weight

Shock and vibration

Parameter
Shock (IEC 60068-2-27)
Random Vibration
(IEC 60068-2-64)

Environmental

Parameter
Operating temperature range
Storage temperature range
Ingress protection
Operating humidity
Storage humidity
Maximum altitude
Pollution degree
Note 7: WebDAQ 504 operation is intended for indoor use only.
Table 16. Power specifications
Conditions Specification
Center positive 6 VDC to 16 VDC
4 W typ, 10 W max
MCC p/n PS- 9 V, 1.67 A, 110 VAC to 240 VAC input range
9V1AEPS230V
One 3 V button cell lithium battery (BR1225 or CR1225) required to
maintain time of day clock when device is powered off.
Table 17. Mechanical specifications
Specification
158.8 × 146.1 × 38.1 mm (6.25 × 5.75 × 1.50 in.)
178.8 × 146.1 × 38.1 mm (7.04 × 5.75 × 1.50 in.) includes BNC connectors
680 g (1.50 lb)
Table 18. Shock and vibration specifications
Conditions Specification
Operational 30 g peak, half-sine, 11 ms pulse
Nonoperating 50 g peak, half-sine, 11 ms pulse
18 shocks at 6 orientations
Operational 5 to 500 Hz, 0.3 g
Nonoperating 5 to 500 Hz, 2.4 g
Table 19. Environmental specifications
Specification
0 °C to 50 °C max
–40 °C to 85 °C
IP30
10 to 90% RH, noncondensing
5% to 95% RH, noncondensing
2,000 m (6,562 ft)
2
25
rms
rms
Specifications
