Summary of Contents for Measurement Computing WebDAQ 504

  • Page 1 WebDAQ 504 Internet Enabled Vibration/Acoustic Data Logger User's Guide October 2017. Rev 1 © Measurement Computing Corporation...
  • Page 2 Other product and company names mentioned herein are trademarks or trade names of their respective companies. © 2017 Measurement Computing Corporation. All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form by any means, electronic, mechanical, by photocopying, recording, or otherwise without the prior written permission of Measurement Computing Corporation.
  • Page 3: Table Of Contents

    Conventions in this user's guide ......................... 5 Where to find more information ......................... 5 Hazardous voltages ............................. 5 Hazardous locations ................................5 Chapter 1 Introducing the WebDAQ 504 ......................6 Powered by Raspberry Pi ® ..........................6 Integrated operating system and web service ..................... 6 Ethernet interface ..............................
  • Page 4 WebDAQ 504 User's Guide Replacing the battery ............................18 Updating WebDAQ firmware ........................... 19 Calibrating the hardware........................... 19 Chapter 4 Specifications ............................20 Analog input ..............................20 Digital input/output............................21 Network ................................22 Ethernet connection .................................22 Network interface ................................22 Network factory default settings ............................22 Processor / Memory ............................
  • Page 5: Preface

    Preface About this User's Guide What you will learn from this user's guide This user's guide describes the Measurement Computing WebDAQ 504 data acquisition device and the web interface, and lists device specifications. Conventions in this user's guide For more information Text presented in a box signifies additional information related to the subject matter.
  • Page 6: Introducing The Webdaq 504

    WebDAQ Series devices are designed with an integrated operating system and web interface. You communicate with the device over a network connection using the web interface opened in a web browser. Mobile support – access the WebDAQ 504 from any device with a web browser, such as a phone or tablet ...
  • Page 7: Functional Block Diagram

    Introducing the WebDAQ 504 Functional block diagram Device functions are illustrated in the block diagram shown here. Figure 1. WebDAQ 504 functional block diagram Unpacking As with any electronic device, you should take care while handling to avoid damage from static electricity.
  • Page 8: Setting Up The Webdaq 504

    IP address from a DHCP server. If this fails, a link-local address is used. Use of a static address requires configuration via the web interface. The IP address identifies the WebDAQ 504 on the network, and is used to access the web interface.
  • Page 9: Detecting The Device On The Network

    WebDAQ 504 User's Guide Setting up the WebDAQ 504 Detecting the device on the network WebDAQ uses the "zeroconf" zero-configuration protocol to announce its presence on a local area network. Zeroconf uses a device name which can be accessed from other computers on the network.
  • Page 10: Configuring The Webdaq For Wireless Communication

    WebDAQ 504 User's Guide Setting up the WebDAQ 504 Configuring the WebDAQ for wireless communication Once communication is established on a wireless network, you can connect a WiFi adapter to the USB port and use the web interface to configure the WebDAQ for communication over a wireless network. With the WebDAQ connected through the wired connection, perform the following procedure.
  • Page 11: Restoring Factory Default Settings

    WebDAQ 504 User's Guide Setting up the WebDAQ 504 To change the security level or password, open the web interface and go to the Device window, Security tab. Use the device Reset button to restore security settings to factory default values.
  • Page 12: Functional Details

    Chapter 3 Functional Details Front panel components Front panel components are shown in Figure 3. Figure 3. Front panel Screw terminal BNC connectors Screw terminal Connect up to four digital I/O lines ( ) to the detachable screw terminal. Refer to Figure 4 for signal DIO0 DI03 locations.
  • Page 13: Rear Panel Components

    If you make a ground-referenced connection between the signal source and the WebDAQ 504, make sure the voltage on the AI– shell is in the common-mode range to ensure proper operation. The AI- shell is protected against accidental contact with overvoltages within the overvoltage protection range.
  • Page 14: External Power Connector

    WebDAQ 504 User's Guide Functional Details External power connector Connect the external AC adapter that shipped with the device to the connector labeled on the rear EXT PWR panel. The power supply provides 9 VDC, 1.67 A power to the WebDAQ.
  • Page 15: Sd Card Slot

    WebDAQ 504 User's Guide Functional Details Label State Description 3: ERROR Blinking yellow Error condition is detected. This LED blinks even when the software is configured to ignore the error Error state is cleared when the next schedule starts. No error detected...
  • Page 16: Usb Connectors

    The WebDAQ 504 uses common-mode bias current to bias the current-limiting diodes when voltage inputs are connected. When the WebDAQ 504 is using grounded signal sources, the current causes an error that is dependent on the AI– lead impedance, and is approximately 50 ppm of range and 15 ppm of reading per Ω of AI–...
  • Page 17: Data Rates

    Anti-aliasing filters The WebDAQ 504 uses a combination of analog and digital filtering to provide an accurate representation of in- band signals while rejecting out-of-band signals. The filters discriminate between signals based on the frequency range, or bandwidth, of the signal.
  • Page 18: Stopband

    Alias-free bandwidth Any signal that appears in the alias-free bandwidth of the WebDAQ 504 is not an aliased artifact of signals at a higher frequency. The alias-free bandwidth is defined by the ability of the filter to reject frequencies above the stopband frequency, and it is equal to the data rate minus the stopband frequency.
  • Page 19: Updating Webdaq Firmware

    FAQ for instructions. Updating WebDAQ Firmware Calibrating the hardware The Measurement Computing Manufacturing Test department performs the initial factory calibration. Return the device to Measurement Computing Corporation when calibration is required. The recommended calibration interval is one year.
  • Page 20: Specifications

    Chapter 4 Specifications All specifications are subject to change without notice. Typical for 0 °C to 50 °C unless otherwise specified. Analog input Table 1. Analog input specifications Parameter Condition Specification Number of channels 4 analog input channels ADC resolution 24 bits Type of ADC Delta-Sigma (with analog prefiltering)
  • Page 21: Digital Input/Output

    ± V ) must be 0 to 19, where common-mode bias full-scale is the common-mode voltage applied to the WebDAQ 504. common-mode is the bias voltage of the IEPE sensor. bias is the full-scale voltage of the IEPE sensor. full-scale Table 2.
  • Page 22: Network

    WebDAQ 504 User's Guide Specifications Parameter Specification Input high voltage limit 15 V max –0.5 V absolute min Input low voltage limit 0 V recommended min 0 V to +5 V (no external pull up resistor) Output voltage range 0 V to +15 V max (Note 4) Output off state leakage 10 µA max...
  • Page 23: Processor / Memory

    WebDAQ 504 User's Guide Specifications Parameter Specification Factory default user name admin, case sensitive; cannot be changed. Processor / Memory Table 9. Processor / memory specifications Parameter Specification Microprocessor Type: Quad core Broadcom BCM2837 Speed: 1.2 GHz Memory RAM: 1 GB LPDDR2...
  • Page 24: Push Buttons

    WebDAQ 504 User's Guide Specifications Label State Description 4: MEDIA Blinking yellow A job is configured to log to external media, but the job hasn't started yet; push button will not let you eject media. Steady yellow External media is inserted into the SD card slot or USB storage port.
  • Page 25: Power

    –40 °C to 85 °C Ingress protection IP30 Operating humidity 10 to 90% RH, noncondensing Storage humidity 5% to 95% RH, noncondensing Maximum altitude 2,000 m (6,562 ft) Pollution degree Note 7: WebDAQ 504 operation is intended for indoor use only.
  • Page 26: Safety Voltages

    Such voltage measurements include signal levels, special equipment, limited-energy parts of equipment, circuits powered by regulated low-voltage sources, and electronics. Caution! Do not connect the WebDAQ 504 to signals or use for measurements within Measurement Categories II, III, or IV.
  • Page 27: Eu Declaration Of Conformity

    May 31, 2017, Norton, Massachusetts USA Test Report Number: EMI7018.17 Measurement Computing Corporation declares under sole responsibility that the product WebDAQ 504 is in conformity with the relevant Union Harmonization Legislation and complies with the essential requirements of the following applicable European Directives:...
  • Page 28 Measurement Computing Corporation NI Hungary Kft 10 Commerce Way H-4031 Debrecen, Hátar út 1/A, Hungary Norton, Massachusetts 02766 Phone: +36 (52) 515400 (508) 946-5100 Fax: +36 (52) 515414 Fax: (508) 946-9500 http://hungary.ni.com/debrecen E-mail: info@mccdaq.com www.mccdaq.comw...
