USB-1808X User's Guide

USB

Parameter
USB device type
Device compatibility
USB cable type
USB cable length

Environmental

Parameter
Operating temperature range
Storage temperature range
Humidity

Mechanical

Parameter
Dimensions (L × W × H)
User connection length

Screw terminal connector

Parameter
Connector type
Wire gauge range
Table 19. USB specifications
Specification
USB 2.0 (high-speed)
USB 1.1, USB 2.0, USB 3.0
A-B cable, UL type AWM 2725 or equivalent. (Min 24 AWG VBUS/GND,
min 28 AWG D+/D–)
3 m (9.84 ft) max
Table 20. Environmental specifications
Specification
0 °C to 55 °C max
–40 °C to 85 °C max
0% to 90% non-condensing max
Table 21. Mechanical specifications
Specification
127 × 89.9 × 35.6 mm (5.00 × 3.53 × 1.40 in.)
3 m (9.84 ft) max
Table 22. Screw terminal connector specifications
Specification
Screw terminal
16 AWG to 30 AWG
25
Specifications
