USB-1808X-OEM User's Guide
USB
Parameter
USB device type
Device compatibility
USB cable type
USB cable length
Environmental
Parameter
Operating temperature range
Storage temperature range
Humidity
Mechanical
Parameter
Dimensions (L × W × H)
User connection length
Header connector
Parameter
Connector type
Wire gauge range
Table 19. USB specifications
Specification
USB 2.0 (high-speed)
USB 1.1, USB 2.0, USB 3.0
A-B cable, UL type AWM 2725 or equivalent. (Min 24 AWG VBUS/GND,
min 28 AWG D+/D–)
3 m (9.84 ft) max
Table 20. Environmental specifications
Specification
0 °C to 55 °C max
–40 °C to 85 °C max
0% to 90% non-condensing max
Table 21. Mechanical specifications
Specification
119.38 × 86.36 × 1.57 (4.7 × 3.4 × 0.062 in.)
3 m (9.84 ft) max
Table 22. Header connector specifications
Specification
Two 1 × 28 pin 0.1 in. pitch headers
16 AWG to 30 AWG
25
Specifications
