USB-5201 User's Guide

USB specifications

USB device type
Device compatibility
USB cable type
USB cable length

Environmental

Operating temperature range
Storage temperature range
Humidity

Mechanical

Dimensions
User connection length

Screw terminal connector type and pin out

Connector type
Wire gauge range
Table 13. USB specifications
USB 2.0 (full-speed)
USB 1.1, USB 2.0
Self-powered, 500 mA consumption max
A-B cable, UL type AWM 2527 or equivalent. (min 24 AWG VBUS/GND,
min 28 AWG D+/D-)
3 meters max.
Table 14. Environmental specifications
0 to 70 ° C
-40 to 85 ° C
0 to 90% non-condensing
Table 15. Mechanical specifications
127 mm (L) x 88.9 mm (W) x 35.56 (H)
3 meters max.
Table 16. Screw terminal connector specifications
Screw terminal
16 AWG to 30 AWG
27
Specifications
