Atmel Smart Microcontrollers
SAMHA1G16A Xplained Pro
USER GUIDE
Preface
®
The Atmel
SAMHA1G16A Xplained Pro evaluation kit is a hardware
platform to evaluate the ATSAMHA1G16A microcontroller.
Supported by the Atmel Studio integrated development platform, the kit
provides easy access to the features of the Atmel ATSAMHA1G16A and
explains how to integrate the device in a custom design.
The Xplained Pro MCU series evaluation kits include an on-board
Embedded Debugger, and no external tools are necessary to program or
debug the ATSAMHA1G16A.
The Xplained Pro extension kits offers additional peripherals to extend the
features of the board and ease the development of custom designs.
Atmel-00001-SAMHA1G16A-Xplained-Pro_User Guide-11/2014
Advertisement
Table of Contents
Related Manuals for Atmel SAMHA1G16A Xplained Pro
Summary of Contents for Atmel SAMHA1G16A Xplained Pro
-
Page 1: Preface
ATSAMHA1G16A microcontroller. Supported by the Atmel Studio integrated development platform, the kit provides easy access to the features of the Atmel ATSAMHA1G16A and explains how to integrate the device in a custom design. The Xplained Pro MCU series evaluation kits include an on-board Embedded Debugger, and no external tools are necessary to program or debug the ATSAMHA1G16A. -
Page 2: Table Of Contents
SAMHA1G16A Xplained Pro Introduction................... 3 1.2. SAMHA1G16A Xplained Pro Feature list..................3 2. Getting Started......................5 2.1. Xplained Pro Quick Start......................5 2.2. SAMHA1G16A Xplained Pro Design Documentation and relevant links........5 3. Xplained Pro......................6 3.1. Embedded Debugger........................6 3.2. Hardware Identification System....................7 3.3. -
Page 3: Introduction
1.1. SAMHA1G16A Xplained Pro Introduction The Atmel SAMHA1G16A Xplained Pro evaluation kit is a hardware platform to evaluate the Atmel ATSAMHA1G16A. The kit offers a set of features that enables the ATSAMHA1G16A user to get started with the SAM HA1 peripherals right away and to get an understanding of how to integrate the device in their own design. - Page 4 One green board power LED – Programming and debugging – Data Gateway Interface: I C, SPI and four GPIOs – Virtual COM port (CDC) • USB powered • Supported with application examples in Atmel Software Framework Atmel SAMHA1G16A Xplained Pro [USER GUIDE] Atmel-00001-SAMHA1G16A-Xplained-Pro_User Guide-11/2014...
-
Page 5: Getting Started
, Windows 7, Windows 8, Windows 10, and Windows Server 2012. Once the Xplained Pro MCU board is powered the green power LED will be lit and Atmel Studio will auto detect which Xplained Pro MCU- and extension board(s) are connected. Atmel Studio will present relevant information like datasheets and kit documentation. -
Page 6: Xplained Pro
Atmel Data Visualizer is used to send and receive data through DGI. The EDBG controls two LEDs on SAMHA1G16A Xplained Pro; a power LED and a status LED. The table below shows how the LEDs are controlled in different operation modes. -
Page 7: Hardware Identification System
3000 Maximum Voltage [mV] uint16_t 3600 Maximum Current [mA] uint16_t 3.3. Power Sources The SAMHA1G16A Xplained Pro kit can be powered by several power sources as listed in the table below. Atmel SAMHA1G16A Xplained Pro [USER GUIDE] Atmel-00001-SAMHA1G16A-Xplained-Pro_User Guide-11/2014... -
Page 8: Xplained Pro Headers And Connectors
Table 3-3. Power Sources for SAMHA1G16A Xplained Pro Power input Voltage requirements Current requirements Connector marking External power 5V ±2% (±100mV) for Recommended USB host operation. minimum is 1A to be 4.3V to 5.5V if USB host able to provide enough... - Page 9 Xplained Pro Power Header The power header can be used to connect external power to the SAMHA1G16A Xplained Pro kit. The kit will automatically detect and switch to any external power if supplied. The power header can also be used as supply for external peripherals or extension boards.
- Page 10 Regulated 3.3V (output, used as main power supply for the kit) 3.4.3. [COMMON] Xplained Pro HV Header Enter a short description of your topic here (optional). This is the start of your topic. Atmel SAMHA1G16A Xplained Pro [USER GUIDE] Atmel-00001-SAMHA1G16A-Xplained-Pro_User Guide-11/2014...
-
Page 11: Hardware User Guide
4.1.1. Xplained Pro Extension Headers The SAMHA1G16A Xplained Pro header EXT1 offers access to the I/O of the microcontroller in order to expand the board e.g. by connecting extensions to the board. This header is based on the standard extension header specified in Table 3-4 . - Page 12 Table 4-3. Extension Header HV HV pin SAMHA1 Function Shared functionality 1 [ID] Communication line to the ID chip on an extension board. 2 [GND] Ground. 5 [LIN_GND] Ground. 7 [LIN] LIN Bus Atmel SAMHA1G16A Xplained Pro [USER GUIDE] Atmel-00001-SAMHA1G16A-Xplained-Pro_User Guide-11/2014...
- Page 13 An angled 1x2, 100mil pin-header marked with MCU current measurement is located at the upper edge of the SAMHA1G16A Xplained Pro. All power to the ATSAMHA1G16A is routed through this header. To measure the power consumption of the device remove the jumper and replace it with an ammeter.
-
Page 14: Peripherals
4.2.1. Mechanical buttons SAMHA1G16A Xplained Pro contains two mechanical buttons. One button is the RESET button connected to the SAMHA1 reset line and the other is a generic user configurable button. When a button is pressed it will drive the I/O line to GND. - Page 15 RESET PB03 4.2.2. There is one yellow LED available on the SAMHA1G16A Xplained Pro board that can be turned on and off. The LED can be activated by driving the connected I/O line to GND. Table 4-7. LED Connection SAMHA1 pin...
-
Page 16: Embedded Debugger Implementation
Virtual Com port interface over UART, an Atmel Data Gateway Interface over I C and SPI and it includes four of the SAM HA1 GPIOs. Atmel Studio can be used as a front end for the Embedded Debugger. 4.3.1. Serial Wire Debug The Serial Wire Debug (SWD) uses two pins to communicate with the target. - Page 17 For further information on how to configure and use the GPIO monitoring features, see Atmel Data Visualizer and the EDBG User Guide. Table 4-15. GPIO Lines Connected to the EDBG SAMHA1 pin Function Shared functionality PB03 GPIO0 PB16 GPIO1 EXT3 PB17 GPIO2 EXT3 PA01 GPIO3 EXT3 Atmel SAMHA1G16A Xplained Pro [USER GUIDE] Atmel-00001-SAMHA1G16A-Xplained-Pro_User Guide-11/2014...
-
Page 18: Hardware Revision History And Known Issues
5.1. Identifying Product ID and Revision The revision and product identifier of Xplained Pro boards can be found in two ways; either through Atmel Studio or by looking at the sticker on the bottom side of the PCB. By connecting an Xplained Pro MCU board to a computer with Atmel Studio running, an information window will pop up. -
Page 19: Samha1G16A Xplained Pro Revision History
SAMHA1G16A Xplained Pro Revision History Doc. rev. Date Comment 01/2016 Initial release Atmel SAMHA1G16A Xplained Pro [USER GUIDE] Atmel-00001-SAMHA1G16A-Xplained-Pro_User Guide-11/2014... -
Page 20: Evaluation Board/Kit Important Notice
(WEEE), FCC, CE or UL (except as may be otherwise noted on the board/kit). Atmel supplied this board/kit "AS IS," without any warranties, with all faults, at the buyer's and further users' sole risk. The user assumes all responsibility and liability for proper and safe handling of the goods. -
Page 21: Fcc_Note
FCC_note Atmel SAMHA1G16A Xplained Pro [USER GUIDE] Atmel-00001-SAMHA1G16A-Xplained-Pro_User Guide-11/2014... - Page 22 DISCLAIMER: The information in this document is provided in connection with Atmel products. No license, express or implied, by estoppel or otherwise, to any intellectual property right is granted by this document or in connection with the sale of Atmel products. EXCEPT AS SET FORTH IN THE ATMEL TERMS AND...
