RING SAW
ORIGINAL INSTRUCTIONS
For your personal safety, READ and UNDERSTAND before using.
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
Warning:
On tools equipped with over load protection, when motor has been cut off due to over load,
always switch on machine with no load for at least 3 minutes to reduce temperature before
returning to operation to avoid burn out of the motor.
Advertisement
Table of Contents
Related Manuals for AGP R13
Summary of Contents for AGP R13
- Page 1 RING SAW ORIGINAL INSTRUCTIONS For your personal safety, READ and UNDERSTAND before using. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE. Warning: On tools equipped with over load protection, when motor has been cut off due to over load, always switch on machine with no load for at least 3 minutes to reduce temperature before returning to operation to avoid burn out of the motor.
- Page 2 SPECIFICATIONS Power 220-240V:3200W (16A) 110-120V:3000W (25A) Voltage 220-240V~ 50/60Hz or 110-120V~ 50/60Hz (See Machine Nameplate) No Load Speed/min 2850 Linear Speed 49.2 m/s Blade Diameter 330mm (13") Max. Depth of Cut 220mm (8.7") Dimensions (incl. blade) 730 x 280 x 450mm Weight 12.6kg ( 27.7 Lbs) (not including blade) 1.
-
Page 3: General Safety Rules
General Safety Rules WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fi re and/or serious injury. Save all warnings and instructions for future reference. The term “power tool” in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool. - Page 4 Prevent unintentional starting. Ensure the switch is in the off-position before connecting to power source and/or battery pack, picking up or carrying the tool. Carrying power tools with your finger on the switch or energising power tools that have the switch on invites accidents. Remove any adjusting key or wrench before turning the power tool on.
-
Page 5: Symbols Used In This Manual
Symbols used in this manual ..always wear eye protection V……..volts ..always wear a dust mask. A……..amperes Hz……..hertz ..always wear hearing protection W……..watt ~………..alternating current ..wear safety-approved hard hat ………...rated speed …..revolutions or reciprocation ..DANGER! Keep hands away from cutting area per minute and the blade. -
Page 6: Kickback And Related Warnings
tool or wheel is dropped, inspect for damage or install an undamaged wheel. After inspecting and installing the wheel, position yourself and bystanders away from the plane of the rotating wheel and run the power tool at maximum no load speed for one minute. Damaged wheels will normally break apart during this test time. -
Page 7: Electrical Connection
accessory. Corners, sharp edges or bouncing have a tendency to snag the rotating accessory and cause loss of control or kickback. • Do not attach a saw chain, woodcarving blade, segmented diamond wheel with a peripheral gap greater than 10 mm or toothed saw blade. Such blades create frequent kickback and loss of control. •... -
Page 8: Diamond Blades
INTRODUCTION This machine is equipped with two handles and a blade guard. It has an integrated water feed system as required for diamond cutting. It is equipped with a portable residual current device (PRCD) aka GFCI for electrical safety as well as overload and thermal protection. It must only be used with a diamond blade. It is intended for cutting masonry, stone, concrete, reinforced concrete and similar materials. -
Page 9: Mounting The Blade
remove the slurry from the cut, and extend the life of the blade. The diamond impregnated segments operate on a principle of controlled erosion. The bond matrix holding the diamonds is continually worn away by abrasion with the workpiece, exposing the harder diamonds to stand proud from the bond matrix. -
Page 10: Splash Guards
Use the T-handle wrench on the arbor bolt and rotate it back and forth while tightening the drive tensioner knob until there is just enough tension so that the drive wheel is turning the blade without skidding. Then tighten a further 1/4 turn. Do not over tension. Slide the drive wheel cover plate into position over the drive wheel and tighten the thumb knob. - Page 11 NOTE: Contaminants in the water supply can easily plug up the fine water nozzles in the blade guard. Ensure that the supply water is clean. If you find that there is no water flow to the blade, then clean out the water feed system on the machine with compressed air.
-
Page 12: Before Cutting
• Never lean over the blade path. That would put your body in line with the blade if it kicks back. • Do not cut above shoulder height. • Never cut while standing on a ladder or other unstable platform. Before cutting •... -
Page 13: Daily Maintenance
blade before proceeding to make the main ccut with the ring saw. This will save wear on the ring saw blade. Take care to avoid the blade being pinched. • In round workpieces, the best technique is to use a slow, uniform back and forth motion while cutting with the bottom quadrant of the blade. - Page 14 Brush Cover If the replacement of the power supply cord is necessary, this has to be done by the manufacturer or their agent in order to avoid a safety hazard. WARNING: All repairs must be entrusted to an authorized service center.
-
Page 15: Exploded View
EXPLODED VIEW... -
Page 16: Parts List
PARTS LIST Parts Name Q'ty Parts Name Q'ty POWER SUPPLY CABLE (UK-2.5x3Cx3M-H07RNF) SPRING PIN (Ø5 x 20) POWER SUPPLY CABLE (NO PLUG-1.5x3Cx3M-H07RNF) PANHEAD MACHINE SCREW (M5x35xP0.8) POWER SUPPLY CABLE (UL-12AWGx3Cx3M-SJTW) CRIMP CAP CONNECTOR (C4) POWER SUPPLY CABLE (VDE-1.5x3Cx3M-H07RNF) CRIMP CAP CONNECTOR (C5) PRCD INTERRUPTER PROTECTION (220V) WIRE LEAD (1007-20#35CM) CORD ARMOR... - Page 17 Parts Name Q'ty Parts Name Q'ty INTERNAL CIRCLIP (R-32) SOCKET CAP SCREW (M6x25xP1.0) OILSEAL TRUSS HEAD MACHINE SCREW (M4x10xP0.7) GUIDE ROLLER TENSION ADJUSTOR SCREW HEX WASHER TENSION ADJUSTOR SLEEVE SOCKET SET SCREW (M4x10xP0.7) GASKET LOWER SPLASH GUARD FLAT WASHER (Ø18xØ22x1) TORSION SPRING COIL SPRING RETAINING PLATE...
