Page 1: Instruction Manual
INSTRUCTION MANUAL Original instructions For your personal safety, READ and UNDERSTAND before using. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE. Version:20121008... -
Page 2: Specifications
SPECIFICATIONS Power Input 800W 1100W 1300W Voltage See machine nameplate N-m (Low Gear / High Gear) 11.0 27.4/17.3 Number of Gears No Load min 250-700 150-400 / 250-700 Protection Double Insulation / Class II Coupling Thread M14 - 2.0 M14 - 2.0 M14 - 2.0 Mixing Paddle Max. - Page 3 GENERAL SAFETY INSTRUCTIONS WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. The term “power tool” in the warnings refers to your mainsoperated (corded) power tool or battery-operated (cordless) power tool.
- Page 4 b) Use personal protective equipment. Always wear eye protection. Protective equipment such as dust mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce personal injuries. c) Prevent unintentional starting. Ensure the switch is in the off-position before connecting to power source and/or battery pack, picking up or carrying the tool.
-
Page 5: Symbols Used In This Manual
5) SERVICE a) Have your power tool serviced by a qualified repair person using only identical replacement parts. This will ensure that the safety of the power tool is maintained. Symbols used in this manual V……..volts A……..amperes Hz……hertz W……..watt ~………alternating current ………no load speed ……..revolutions or reciprocation per minute ..class II tool... -
Page 6: Functional Description
FUNCTIONAL DESCRIPTION Speed adjustor wheel Spindle Mixing paddle Gear Selector Trigger switch with lock pin Fig.1 Safety interlock switch Quick release collars A1 Left twist mixing paddle Trigger switch Speed adjustor wheel A2 Right twist mixing paddle Fig.2 These machines are electric stirrers designed to Mix various mediums. -
Page 7: Carton Contents
UNPACKING Carefully remove the tool and all loose items from the shipping container. Retain all packing materials until after you have inspected and satisfactorily operated the machine. NOTE: An appropriate paddle must be mounted to the machine before operating. Refer the section of this manual: “INSTALLING THE PADDLE” CAUTION: Ensure that the paddle diameter does not exceed the machine’s maximum rated capacity as listed on the machine nameplate and that the thread of the coupling is correct. -
Page 8: All Other Models
REMOVING THE PADDLE- ENSURE THAT TOOL IS DISCONNECTED FROM POWER SOURCE. Double paddle models only: Pull outwards the knurled quick release collar (65) and pull the paddle outwards to remove the paddle. See Fig.2. All other models: Using the open-end wrench (40) on the flats on the spindle (01) and stabilizing the mixing paddle (41), loosen and then unscrew the paddle from the spindle. - Page 9 Speed Adjustment (Variable speed control models only): Speed adjustor wheel By turning the thumb operated adjustor wheel (45), the speed may be adjusted electronically for best mixing performance in a given medium. See Fig.6. Fig.6 Gear Changes (Two speed range models only): On 2 speed range models, there is a gear selector slider (48) on the gearbox housing.
-
Page 10: How To Use The Tool
HOW TO USE THE TOOL Effective control of this machine requires two-handed operation for maximum protection and resistance to the start-up and operating torque. Place the work properly and to hold the machine firmly WITH BOTH HANDS to prevent loss of control which could cause personal injury. - Page 11 800W WIRING...
- Page 12 1100W, 1300W WIRING...
- Page 13 1600W, Twin Paddle(1600W) WIRING...
- Page 14 800W EXPLODED VIEW...
- Page 15 800W PARTS LIST Parts Name Q'TY SPINDLE M14 x P2.0 PARALLEL KEY 5 x 5 x 12 OIL SEAL Ø22 x Ø32 x 7 SCREW M5 x 60 GEAR HOUSING NEEDLE BEARING HK 1010 BEARING 6003 zz INTERNAL CIRCLIP R-35 EXTERNAL CIRCLIP S-17 OUTPUT GEAR...
- Page 16 1100W EXPLODED VIEW...
- Page 17 1100W PARTS LIST Parts Name Q'TY Parts Name Q'TY SPINDLE M14 x P2.0 SCREW M5 x 45 PARALLEL KEY 5 x 5 x 12 HANDLE BODY (TOP) OIL SEAL Ø22 x Ø32 x 7 HANDLE BODY (BOTTOM) SCREW M5 x 60 SCREW M4 x 20 GEAR HOUSING TRIGGER SWITCH 8301...
- Page 18 1300W EXPLODED VIEW...
- Page 19 1300W PARTS LIST Parts Name Q'TY Parts Name Q'TY SPINDLE M14 x P2.0 HANDLE BODY (TOP) PARALLEL KEY 5 x 5 x 12 HANDLE BODY (BOTTOM) OIL SEAL Ø22 x Ø32 x 7 SCREW M4 x 20 SCREW M5 x 60 TRIGGER SWITCH 8301 GEAR HOUSING SCREW M4 x 14...
- Page 20 1600W EXPLODED VIEW...
- Page 21 1600W PARTS LIST Parts Name Q'TY Parts Name Q'TY SPINDLE M14 x P2.0 SCREW M4 x 20 WOODRUFF KEY 5 x 5 x 12 TRIGGER SWITCH 8301 SEAL Ø22 x Ø32 x 7 SCREW M4 x 14 SCREW M5 x 60 CORD CLIP GEAR HOUSING EMC CAPACITOR(OPTIONAL)
- Page 22 Twin Paddle(1600W) EXPLODED VIEW...
- Page 23 Twin Paddle(1600W) PARTS LIST Parts Name Q'TY Parts Name Q'TY SPINDLE-LONG M18 x P2.5 - R 46.0 SPEED ADJUSTOR 220V SPINDLE-SHORT M18 x P2.5 - L 46.1 SPEED ADJUSTOR 110V WOODRUFF KEY 5 x 5 x 12 47~50 WIRE SHEATH M4 x 8CM 0.08 SCREW M5 x 60 FAN SHROUD...
