AGP LY16 Instruction Manual

Electric nibbler
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Warning:
Only tools equipped with over load
protection, when motor has been cut off
due to over load, always switch on machine
with no load for at least 3 minutes to
reduce temperature before switch on again
to avoid burn out to the motor.
INSTRUCTION MANUAL
ORIGINAL INSTRUCTIONS
For your personal safety,
READ and UNDERSTAND before using.
SAVE THESE INSTRUCTIONS
FOR FUTURE REFERENCE.
Version:20150909

Advertisement

Table of Contents
loading

Related Manuals for AGP LY16

Summary of Contents for AGP LY16

  • Page 1 INSTRUCTION MANUAL Warning: ORIGINAL INSTRUCTIONS Only tools equipped with over load For your personal safety, protection, when motor has been cut off READ and UNDERSTAND before using. due to over load, always switch on machine with no load for at least 3 minutes to SAVE THESE INSTRUCTIONS reduce temperature before switch on again FOR FUTURE REFERENCE.
  • Page 2 Power Input 500W Voltage See machine nameplate No Load/min 2300 SPM Min. Cut Radius 40mm Steel 1.6mm (16 ga. ) Max. Capacity Stainless Steel 1.2mm (18 ga.) Dimensions 790mm x 270mm x 730mm Net Weight 1.5kg (3.3Lbs) Locking slider switch Externally accessible brushes Slim line motor Rotatable die assy.

  • Page 3: General Safety Instructions

    GENERAL SAFETY INSTRUCTIONS When operating a power tool outdoors, use an extension cord suitable for outdoor use. WARNING! Read all safety warnings and Use of a cord suitable for outdoor use reduces all instructions. Failure to follow the the risk of electric shock. I f o p e rat i n g a p owe r to o l i n a d a m p warnings and instructions may result in location is unavoidable, use an ear th...
  • Page 4 ensure these are connected and properly used. 5) SERVICE Use of dust collection can reduce dust-related Have your power tool serviced by a qualified hazards. repair person using only identical replacement parts. This will ensure that the safety of the power 4) POWER TOOL USE AND CARE tool is maintained.

  • Page 5: Special Precautions

    SPECIAL PRECAUTIONS: CUTTING BEWARE:The nibbler leaves a very sharp edge Do not attempt to cut sheet metal that is on the workpiece.do not handle the edge with beyond the maximum rated thickness for this your bare hands. tool. Ensure that the power cord is not cut or Use cutting oil along the cut to be made.

  • Page 6: Pocket Cutting

    POCKET CUTTING PUNCH AND DIE Before begining you must drill or punch a hole at The punch and die are wearing parts. Periodically least 23mm in diameter.Then proceed to cut inspec t their cutting sur faces. Wear will be pocket. especially quick when cutting trapezoidal sheet metal.

  • Page 7: Switching The Machine On And Off

    HOW TO USE THE TOOL screw. Effective control of this machine requires two- handed operation for maximum safety and Piston control. Punch Set Screw The proper hold is to keep one hand on the main handle and the other hand on the grip . It is vitally important to keep stable footing at all times, Die Holder OPERATIONS...
  • Page 8 THE CARBON BRUSHES It is recommended that, at least once a year, you take the tool to an Authorized Service Center for a The carbon brushes are a normal wearing part and thorough cleaning and lubrication. must be replaced when they reach their wear limit. NOTE: Checking and replacing the carbon I f th e re p la ce m e nt o f t h e p owe r s up p ly brushes should be entrusted to a qualified...
  • Page 9 WIRING...

  • Page 10: Exploded View

    EXPLODED VIEW...

  • Page 11: Parts List

    PARTS LIST Parts Name Q'TY Parts Name Q'TY SCREW M3 x 15 FAN BAFFLE SCREW M4 x 2-1/2"(63.5) DIE HOLDER STATOR PUNCH MOTOR HOUSING SOCKET SET SCREW M5 x 5 SWITCH SUPPORT PISTON SCREW M4 x 12 WRIST PIN Ø6 x 12.8 BRUSH HOLDER CONNECTING ROD CARBON BRUSH 6.5 x 7.5...
