About This Manual Purpose This manual describes how to install the ZXSDR R8119 Pico Remote Radio Unit. Intended Audience Installation engineers Device supervision engineers Maintenance engineers What Is in This Manual This manual contains the following chapters. Chapter 1, Installation Describes the interfaces involved in installation.
Page 6
This page intentionally left blank. SJ-20150805085318-002|2016-08-18 (R1.3) ZTE Proprietary and Confidential...
Mounts the ZXSDR R8119 to installation components. ETH interface RJ45 network interface, supports the function, used for the ZXSDR R8119 to connect to the ETH interface of the Pbridge (a remote convergence unit) through an Ethernet cable. ANT interface Interface complete with external antenna connection SJ-20150805085318-002|2016-08-18 (R1.3)
Page 8
ZXSDR R8119 Hardware Installation This page intentionally left blank. SJ-20150805085318-002|2016-08-18 (R1.3) ZTE Proprietary and Confidential...
Installing a Removable Ceiling .................2-11 2.1 Installing the Device on a Pole This procedure describes how to install the ZXSDR R8119 against a vertical pole. The diameter of a pole is 8 to 30 mm. For the installation components, refer to the following table.
Page 10
ZXSDR R8119 Hardware Installation Component Quantity Overview Pole holder Vertical pole fixture M5 × 25 countersunk screw Wing nut and washer Slide-proof rubber mat Steps 1. Wrap the slide-proof rubber mat around the pole, see Figure 2-1. SJ-20150805085318-002|2016-08-18 (R1.3) ZTE Proprietary and Confidential...
Chapter 2 Installing the ZXSDR R8119 Figure 2-1 Wrapping the Slide-Proof Rubber Mat Around the Pole 2. Secure the two-point mounting plate to the L-shaped bracket with two countersunk-head screws (M5 × 25) and two wing nuts and washers, see Figure 2-2.
Figure 2-3 Securing the Pole Bracket to the Pole 4. Align the two U-shape grooves of the ZXSDR R8119 with the two rivets on the two-point hanging board and push the ZXSDR R8119 to the end to fix it on the two-point hanging...
Page 13
Chapter 2 Installing the ZXSDR R8119 Context For the installation components, refer to the following table. Component Quantity Overview Two-point hanging plate L-shaped bracket Wing nut and washer M5 × 25 countersunk screw ST4.2 × 32 countersunk self-tapping screws φ6×30 Expansion pipe Steps 1.
ZXSDR R8119 Hardware Installation Figure 2-5 Securing the Two-Point Mounting Plate to the L—shaped Bracket 2. On the wall, mark locations for drilling holes based on the hole positions of the L-shaped bracket, and drill four holes at the marks with an electric drill. The holes...
Figure 2-8 Securing the L-shaped Bracket to the Wall 5. Align the two U-shape grooves of the ZXSDR R8119 with the two rivets on the two-point hanging plate, and push the ZXSDR R8119 to the end to fix it on the two-point hanging...
When installing the ZXSDR R8119 against a cement ceiling, ensure that the distance between the plastic shell top of the ZXSDR R8119 and the ceiling is not less than 40 mm. This requirement can be met through the wall-mount fixture between the ZXSDR R8119 and the cement ceiling.
Page 17
Chapter 2 Installing the ZXSDR R8119 Component Quantity Overview Wall-mount fixture ST4.2 × 19 countersunk self-tapping screws ST4.2 × 32 countersunk self-tapping screws φ6×30 Expansion pipe Steps 1. Drill holes in the ceiling. a. Make marks on the cement ceiling in accordance with the holes of the wall-mount fixture to determine the locations of the holes to be drilled.
ZXSDR R8119 Hardware Installation Figure 2-10 Installing Expansion Pipes 3. Use two countersunk self-tapping screws (ST4.2 × 19) to fix the two-point hanging board to the wall-mount fixture, see Figure 2-11. Figure 2-11 Fixing Two-Point Hanging Plate to the Wall-Mount Fixture 4.
Figure 2-12 Fixing the Wall-Mount Fixture to the Ceiling 5. Align the two U-shape grooves of the ZXSDR R8119 with the two rivets on the two-point hanging plate, and push the ZXSDR R8119 to the end to fix it on the two-point hanging...
Page 20
ZXSDR R8119 Hardware Installation Context For the installation components, refer to the following table. Component Quantity Overview Two-point hanging board L-shaped bracket M5 × 25 countersunk- head screw Wing nut and washer Steps 1. Remove the ceiling, mark the positions for drilling holes on the wall based the hole...
The network cable hole must be drilled in accordance with the size specified on the hole template. If the hole size is smaller than that of the template hole, the network cable will be stuck when the ZXSDR R8119 is dismounted. 2-13 SJ-20150805085318-002|2016-08-18 (R1.3)
2-16. Figure 2-16 Securing the Bracket 4. Align the two U-shape grooves of the ZXSDR R8119 with the two rivets on the two-point hanging plate, and push the ZXSDR R8119 to the end to fix it on the two-point hanging...
The maximum length of an Ethernet cable from the ZXSDR R8119 to the Pbridge should be less than 100 m. Steps 1. Connect one end of the Ethernet cable to the ETH interface of the ZXSDR R8119, see Figure 3-2.
3. Root and bind the cable. 4. Stick a label on the cover of the ZXSDR R8119 and write information on the label to indicate the port and Pbridge that the ZXSDR R8119 is connected. For example, PB1-PORT1 indicates that the ZXSDR R8119 is connected to the first port on the first Pbridge.
Figure 2-2 Securing the Two-Point Mounting Plate to the L-shaped Bracket ..... 2-3 Figure 2-3 Securing the Pole Bracket to the Pole ............2-4 Figure 2-4 Mounting the ZXSDR R8119 ..............2-4 Figure 2-5 Securing the Two-Point Mounting Plate to the L—shaped Bracket ... 2-6 Figure 2-6 Drilling Holes ...................
Page 26
Figures This page intentionally left blank. SJ-20150805085318-002|2016-08-18 (R1.3) ZTE Proprietary and Confidential...
