① PV: Process Value
Measured Value/Mode Value
② SV: Setting Value.
Set Value/ Mode Context Value
③ Status Display LED
OUT：Output pilot lamp
AL1：Alarm1 pilot lamp
AL2：Alarm2 pilot lamp
RUN：Manual pilot lamp
④ Up Key: Increase the value in setting, Keep pressing can increase value quick.
⑤ Down Key: Decrease the value in setting, Keep pressing can increase value quick.
⑥ Move Key: When setting temperature value or parameter, press "《 " Key to switch to
the value needed
Self-Adjustment Key: When SV/PV at normal display, keep pressing the "《 " Key
more than 2S to start or end self-adjusting function.
Shift Key: When SV/PV at normal display, press "《 " Key less than 1S to shift between
automatic and manual control modes.
⑦ SET Key: When SV/PV at normal display, press the SET key to check PV and SV value, keep
pressing it more than 2 seconds can access parameter setting mode.

5. Operation Process

5.1 Input Type

(Table1)
Input Type
Thermocouple
Cu resistance
Platinum
resistance
Inkbird Tech. Co., Ltd.
Input Value
K 0
S 1
Wr 2
T 3
E 4
J 5
B 6
N 7
CU50 20
PT100 21
6
IHC-200 User Manual
Measuring Range
-50～1300º C
-50～1700º C
-0～2300º C
-2000～350º C
0～1000º C
0～1000º C
0～1800º C
0～1300º C
-50～150º C
-200～600º C
