Renishaw OMP40 Installation Manual
Shank adaptor assembly
Hide thumbs
Also See for OMP40:
- Quick start manual (24 pages) ,
- Installation and user manual (46 pages)
Related Manuals for Renishaw OMP40
Summary of Contents for Renishaw OMP40
- Page 1 Installation guide H-2000-4082-02-A OMP40 shank adaptor assembly 3 Nm (0.68 lbf) 3 Nm (0.68 lbf) 3. Grease and 1. Remove. 2. Mount adaptor plate. assemble adaptor. 4. Fit to shank.
- Page 2 Renishaw plc +44 (0)1453 524524 +44 (0)1453 524901 New Mills, Wotton-under-Edge, uk@renishaw.com Gloucestershire, GL12 8JR United Kingdom www.renishaw.com 6 Nm (1.35 lbf) 7. Screw in opposition to adjust runout <5 µm. Fully tighten to 5. Fully tighten. 6. Fit to spindle.
