- Page 1 I N S TA L L AT I O N MA N UA L Seda™ 8” Widespread 2-Handle Faucet FUS-1823 www.kraususa.com I toll free: 1.800.775.0703 I © 2014-2015 Kraus USA Inc.
- Page 2 Thank you for purchasing Kraus We would like to take this opportunity to thank you for your business with Kraus USA. It is our sincere hope that you are completely satisfied with your experience. We welcome any questions or comments you may have, and will be glad to assist you in the future.
-
Page 3: Prior To Installation
∅ Prior to Installation: • Make sure you have all necessary parts by checking the diagram and parts list. If any part is missing or damaged, please contact Kraus Customer Service at 800- 775-0703 for a replacement 1 1/4-18UNF-2A •... - Page 4 FUS-1823 Diagram and Parts List A. Hot Handle Valve E. Spout Mounting Hardware: B. Cold Handle Valve E1. Rubber & Metal U-Washer C. Hot & Cold Handle Mounting E2. Mounting Nut Hardware: F. T-Union C1. Rubber & Metal Washer G. Hot & Cold Waterlines C2.
-
Page 5: Faucet Dimensions
Faucet Dimensions 4.92” 4.92” 125mm 125mm 4.96” 1.8” 1.8” 2.24” 126mm 46mm 46mm 57mm 1 1/4-18UN 9/16”-18UNEF Step 1: Remove mounting hardware and T-union Remove T-union (F) and mounting hardware (E) from spout (D). Remove mounting hardware (C) from hot and cold handle valves (A &... - Page 6 1 1/4-18UNF-2A 9/16”-18UNEF 9/16”-18UNEF Step 2: Install & secure spout Install spout (D) through hole in countertop or sink. Attach rubber & metal U-washer (E1) and mounting nut (E2). Adjust spout (D) to proper position and tighten mounting nut (E2) with adjustable wrench.
- Page 7 Step 4: Connect waterlines to faucet and main valve 1 1/4-18UNF-2A 9/16”-18UNEF 9/16”-18UNEF Secure hot & cold waterlines (G) to hot and cold valves (A & B) (Hand- Tighten Only). Thread other end of waterlines to T-union (F). Attach 3/8 in. OD x 1/2 in. IPS waterlines (H) to copper pipe on valves A.
- Page 8 Replacement Part List - FVS-1823 1. Hot Handle 11. Rubber & Metal U Washer 2. Cold Handle 12. Mounting Nut 3. Set Screw 13. T-Union 4. Cover Button 14. Cold Cartridge 5. Hot Cartridge 15. Cold Valve 6. Hot Valve 16.
-
Page 9: Troubleshooting
Trouble - Shooting If you have followed the instructions carefully and your faucet still does not work properly, take the following corrective steps: P R O B L E M C A U S E A C T I O N Hexagon Nut Leakage under the Hot or cold cartridge (5... - Page 10 If Kraus is unable to provide a replacement and repair is not practical or cannot be made in timely fashion, Kraus may elect to refund the purchase price in exchange for the return of the product.
- Page 11 NON-APPLICABILITY OF THIS WARRANTY By the purchase and use of our products, you agree that Kraus is not liable for incidental, consequential or special damages associated with the return, replacement, installation or use of your product. This includes freight costs,...
