- Page 1 INSTALLATION GUIDE Cirrus 8” Widespread Basin Faucet FUS-13103 www.kraususa.com I Toll Free: 1.800.775.0703 I © 2017 Kraus USA Inc. I REV. October 25, 2017...
- Page 2 Congratulations on the purchase of your new Kraus plumbing fixture! Please keep the box and packaging materials until your product is completely installed. If you have any questions, require technical assistance, or have any problems with your product: DO NOT RETURN TO STORE Please contact our Customer Service Team 1-800-775-0703 / customerservice@kraususa.com...
-
Page 3: Prior To Installation
∅ • Make sure you have all necessary parts by checking the diagram and parts list. If any part is missing or damaged, please contact Kraus Customer Service at 800-775-0703 for a replacement • Turn off the hot and cold water supply at the angle stops and turn on the old faucet to release any built up pressure. - Page 4 Diagram and Parts List A. Hot Handle K. Base O-Ring B. Set Screw (factory-installed in spout base) C. Cover Button L. Rubber Washer D. Base Metal Ring M. Mounting Nut E. Base O-Ring N. T-Union Clip O. T-Union (factory-installed in base metal ring) F.
-
Page 5: Faucet Dimensions
Faucet Dimensions... - Page 6 Lift Rod Drain Diagram and Parts List a. Waste Stopper i. Top Hat Washer j. Drain Off Pole b. Drain c. Rubber Washer k. Washer d. Concave Washer l. Retaining Nut e. Plastic Washer m. Clip f. Mounting Nut n. Lift Pole Rod g.
- Page 8 Step 1: Install lift pole rod and knob Remove lift pole knob (o) and clip (m) from lift pole rod (n). Insert lift pole rod (n), threads up, into the base of the spout (I). Place lift pole knob (o) in the back opening of the spout (I).
- Page 9 Step 3: Install spout Install spout (I) through predrilled hole in sink or countertop with spout base (J), base O-ring (K), and lift pole rod (n) attached. Attach rubber washer (L), and mounting nut (M) Step 4: Secure Spout Adjust spout (I) to proper position and tighten mounting nut (M) with adjustable wrench.
- Page 10 Step 5: Remove hot & cold handles, and base metal rings Remove cover button (C) from handle (R) and loosen set screw (B) with hex wrench (T). Remove handle (R), then remove base metal ring (D) from valve (Q). Insert valve (Q) into hole (Hot: Left, Cold: Right) from underneath.
- Page 11 Step 7: Connect waterlines to faucet and main valve Thread waterlines (P) to hot and cold valve (H & Q) horizontally. Thread other end of waterlines to t-union (O). Attach hot & cold supply lines (not included with faucet) to valve (H & Q) vertically A.
-
Page 12: Install Drain
Install drain • Remove waste stopper (a) from drain (b). Remove tail pipe (i), mounting nut (f ), plastic washer (e), and concave washer (d) from drain (b). Remove retaining nut (12) and washer (k) from tailpipe Installer Tip: Leave top hat washer (i) in drain off pole opening of tailpipe (h) •... - Page 13 Install Drain • Insert waste stopper (a) into drain (b). Make sure slot at end of the waste stopper (a) is facing the rear of the sink • Insert shortest end of drain off pole (j) into drain off pole opening of tailpipe (h).
- Page 14 Step 8: Flush faucet Remove aerator assembly (S). Loosen aerator cover (S3) with adjustable wrench. Remove aerator (S2) and aerator washer (S1). Turn water on for 1 minute to remove any debris. Reassemble aerator assembly (S)
- Page 15 Replacement Part List - FUS-13103 1. Metal Handle - HOT 2. Set Screw 3. Cover Button 4. Base Metal Ring 5. Base O-Ring 6. Cartridge - HOT 7. Rubber Washer 8. Mounting Nut 9. Hot Valve 10. Aerator Washer 11. Aerator 12.
- Page 16 Replacement Part List - Lift Rod Drain 1. Waste Stopper 2. Drain 3. Rubber Washer 4. Concave Washer 5. Plastic Washer 6. Mounting Nut 7. Tailpipe Washer 8. Tailpipe 9. Drain Off Pole 10. Top Hat Washer 11. Washer 12. Retaining Nut 13.
-
Page 17: Troubleshooting
Trouble - Shooting If you have followed the instructions carefully and your faucet still does not work properly, take the following corrective steps: P R O B L E M C A U S E A C T I O N Leakage under handles Hot or cold cartridge (6 Remove cover button... - Page 18 (1) year. The warranty commences from the initial date of purchase by the owner or trade professional, from an authorized Kraus dealer, through the one (1) year term of the original owner or end-user.
- Page 19 Rico shipping charges may apply). International shipping fees are not included. COMMERCIAL WARRANTY Kraus extends the above warranty for a period of one (1) year to purchasers of products for industrial, commercial, and business use. All incidental or consequential damages are specifically excluded. No additional warranties, express or implied, are given, including but not limited to any implied warranty of merchantability or fitness for a particular purpose.
- Page 20 IMPORTANT Register Your Kraus Product Activate Your Warranty Access Premium Customer Support Get Product Information REGISTER TODAY http://www.kraususa.com/registration www.kraususa.com...
