Table 1. ZDS II System Requirements
Recommended Configuration
• Windows XP Professional SP3 or later
• Pentium IV 2.2GHz processor or higher
• 1024MB RAM or higher
• 135 MB hard disk space
• Super VGA Video Adapter
• CD-ROM for installation
• RS232 communication port with
hardware flow control
• USB High-Speed port (when using USB
Smart Cable)
• Ethernet port (when using Ethernet
Smart Cable)
• Internet browser (Internet Explorer or
Netscape)
Always use a grounding strap to prevent damage resulting from electro-
Caution:
static discharge (ESD).
External Power Supply Requirements
The 3-phase motor shipped with your development kit requires power from an adjustable
external power source. The external power source must provide 0 V DC to 24 V DC power
at 3 A. The adjustable power supply leads must be fitted with spade lugs that connects to
spade lugs (P4 and P5) on the 3-Phase Motor Control Application Board (see Figure 1).

Running in Standalone Mode

The Z16FMC Series Motor Control Development Kit is shipped with the sample code from
the Application Note titled Sensorless Brushless DC Motor Control with the Z16FMC
MCU (AN0311) preloaded into the Z16FMC chip's internal Flash memory.
Observe the steps in this section to set up the kit and run the sample code in standalone mode.
Step 1. Connect the 3-Phase Motor to the Board
The 24 V DC 3-phase motor included with the kit features three spade connectors that plug
into spade lugs P1, P2, and P3 on the 3-Phase Motor Control Application Board. Connect
QS007901-1110
Z16FMC Series Motor Control Development Kit
Minimum Configuration
• Windows XP Professional SP3
• Pentium IV 1.2GHz processor
• 512 MB RAM
• 25 MB hard disk space (Application only)
• Super VGA Video Adapter
• CD-ROM for installation
• RS232 communication port with
hardware flow control
• USB High-Speed port (when using USB
Smart Cable)
• Ethernet port (when using Ethernet
Smart Cable)
• Internet browser (Internet Explorer or
Netscape)
Quick Start Guide
Page 2 of 15
