Page 2
00. CONTENT 01. SAFETY INSTRUCTIONS INDEX STANDARDS TO FOLLOW 01. SAFETY INSTRUCTIONS ATTENTION: STANDARDS TO FOLLOW This product is certified in accordance with European Community (EC) safety standards. 02. PACKAGE INSIDE PACKAGE This product complies with Directive 2011/65/EU of the European Parliament and of the Council, of 8 June 2011, on the restriction of the use of certain hazardous substances in 03.
Page 3
02. PACKAGE 03. OPERATOR INSIDE PACKAGE TECHNICAL SPECIFICATIONS Inside the package you will find the following components: MBM6 230V MBM6 110V MBM6 24V 01• 01 electromechanical 08• 01 boom fastening metal plate • Barrier’s Power Supply 230V 50/60Hz 230V 50/60Hz 230V 50/60Hz 02•...
Page 4
03. OPERATOR 03. OPERATOR WARNING LIGHT LOCKING/UNLOCKING The MBM6 barrier is a product developed with the purpose of controlling the access of In case of power failure, the barrier is equipped with a manual unlocking and locking vehicles to private, industrial and commercial areas. system.
Page 5
04. INSTALLATION 04. INSTALLATION INSTALLATION SITE PREPARATION BARRIER’S FIXATION 01• With the bolts already fixed on the It’s important that this order of installation is respected! cement foundation, respecting the Otherwise we can’t assure the correct installation of the barrier and it may not work dimensions of point 2, place the barrier properly.
Page 6
04. INSTALLATION 04. INSTALLATION BOOM ASSEMBLY BOOM SUPPORT INSTALLATION After assembling the boom, you must define the length of it so that you can fix the boom support, as visible on the image above. When the boom’s length is decided, fix it with the two small screws situated at the end of the fix part of the boom.
Page 7
04. INSTALLATION 04. INSTALLATION TOP COVER REMOVAL SPRING ADJUSTMENT PHASE 5 PHASE 4 PHASE 3 PHASE 2 ADJUSTMENT• To adjust the springs, you PHASE 1 01• Open the door using the key 02• Rotate the rod (image above) to must use a wrench to fasten or release supplied to unlock it and then pull it to unlock the cover.
Page 8
04. INSTALLATION 04. INSTALLATION BOOM LEVELING LIMIT-SWITCHES AND STOPPERS ADJUSTMENT After installing the barrier, you must verify the position of the boom while closed. If it The mechanical limit-switches of the barrier isn’t aligned horizontaly when closed, follow the instructions bellow to adjust it. are shown on the image on the left.
