Summary of Contents for Motorline professional MPIE10
- Page 1 MPIE10 MPIE10 INSTALLER AND USER’S MANUAL v1.5 REV. 03/2023...
- Page 2 00. CONTENT 01. SAFETY INSTRUCTIONS INDEX ATENÇÃO 01. SAFETY INSTRUCTIONS This product is certified in accordance with European Community (EC) safety standards. 02. AUTOMATISM TECHNICAL CHARACTERISTICS This product complies with Directive 2011/65/EU of the MANUAL UNLOCKING European Parliament and of the Council, of 8 June 2011, on KIT COMPONENTS the restriction of the use of certain hazardous substances DIMENSIONS...
- Page 3 01. SAFETY INSTRUCTIONS GENERAL WARNINGS • Children shouldn’t play with the product or opening devices to avoid the motorized door or gate from being triggered involuntarily. • This manual contains very important safety and usage information. very important. Read all instructions carefully before beginning the WARNINGS FOR TECHNICIANS installation/usage procedures and keep this manual in a safe place that it can be consulted whenever necessary.
- Page 4 01. SAFETY INSTRUCTIONS RESPONSABILITY September 2009. • Attach the permanent label for the manual release as close as possible • Supplier disclaims any liability if: to the release mechanism. • Product failure or deformation result from improper installation • Disconnect means, such as a switch or circuit breaker on the electrical use or maintenance! panel, must be provided on the product’s fixed power supply leads in •...
- Page 5 02. AUTOMATISM TECHNICAL CHARACTERISTICS KIT COMPONENTS MPIE10 bollards were developed for traffic control, limiting the passage of vehicles. The kit is composed by the following components: Built entirely in 304 stainless steel and PVC, they are anti-vandalism bollard, suitable for underground 01 •...
- Page 6 02. AUTOMATISM 03. INSTALLATION DIMENSIONS AUTOMATISM INSTALLATION Before any installation step, check and make sure that the cable inside the automation 400mm is in accordance with image A, well-adjusted to the support. 204mm cable cable The cable cannot have too much slack inside the automation or wrapped around the motor support rod due to the risk 250mm...
- Page 7 03. INSTALLATION AUTOMATISM INSTALLATION Remove Seal seal • At the base of the bollard, place a drain pipe, with a minimum inclination of 10°. • Leave a tube to pass the electric cable to the control board. • Place sand around the bollard for better accommodation. 200mm •...
- Page 8 04. TROUBLESHOOTING INSTRUCTIONS FOR FINAL CONSUMERS AND SPECIALIZED TECHNICIANS Anomaly Procedure Behavior Procedure II Discovering the origin of the problem • Bollard • Check that the • Still not working. • Consult a qualified 1 • Open control box and check if it 3 •...
