- Page 1 Automatic Bollard English AUTOMATIC BOLLARD ASSEMBLY AND OPERATING MANUAL MPIE10 400/600/800 Please read the manual very carefully before installation V 2.1 R 03/2018...
- Page 2 12) Connect the bollard to a 230V power supply, with ground wire. 13) The equipment is determined for outdoor use. CONFORMITY: Electrocelos S.A. declares, the automatic bollard MPIE10 follows the european norms and directives: 2006/95/CE-Low voltage electrical equipment; 89/336/CEE-Electromagnetic compatibility.
- Page 3 Automatic Bollard Assembly manual of MPIE10 400/600/800 English B) Technical Specifications 1) Motor Specifications: Model WING400/600/800 Input 24 VDC Power 60 W Intensity 1.2 - 4A Thermical Protection 120ºC >-20ºC; <+50ºC Temperature 2) Mechanical Specifications: INOX 2.5 mm Mobile piece...
- Page 4 Automatic Bollard Assembly manual of MPIE10 400/600/800 English C) Underground Bollard Installation Earth Cover Cement 150mm Sand PVC cylinder Solid base (in cement) to Power cable 50mm support MPIE10 10º Protective conduit for cable passage Sewer Figure 1: Bollard scheme CAUTION: 1.
- Page 5 Automatic Bollard Assembly manual of MPIE10 400/600/800 English C) Underground Bollard Installation In order to install the bollard, you can dismount the cover, making the process much easier. To do that, you must remove the 6 screws furthest from the center, marked at red in Fig.2.
- Page 6 Automatic Bollard Assembly manual of MPIE10 400/600/800 English D) Dimensions 250mm Page 05...
- Page 7 Rotate the key in clockwise direction IMPORTANT - After unlocking, the MPIE10 400/600/800 will descend automatically. - In case of power outage, the bollard is prevented by a battery that has enough power to make one maneuvre (open or close). You shall not use the bollard anymore untill there is a power supply at 230V because the battery was designed for emergencies only.
- Page 8 Automatic Bollard Assembly manual of MPIE10 400/600/800 English IMPORTANT This cable can’t be buried in direct contact with the soil. ATTENTION! A protective conduit must be used for underground cable passage. Page 07...
