- Page 1 MR-12 USER’S AND INSTALLER’S MANUAL v1.3 REV. 11/2022...
- Page 2 This product complies with Directive 2011/65/EU of the 02. CONNECTIONS SCHEME European Parliament and of the Council, of 8 June 2011, on MR-12 (EXAMPLE OF A CONNECTION WITH IMPULSE FROM ANOTHER CON- TROL BOARD OR FITTING RECEIVER the restriction of the use of certain hazardous substances in electrical and electronic equipment and with Delegated 03.
- Page 3 01. SAFETY INSTRUCTIONS GENERAL WARNINGS WARNINGS FOR TECHNICIANS • This manual contains very important safety and usage information. • Before beginning the installation procedures, make sure that you have Read all instructions carefully before beginning the installation/ all the devices and materials necessary to complete the installation usage procedures and keep this manual in a safe place that it can be of the product.
- Page 4 01. SAFETY INSTRUCTIONS RESPONSABILITY • Disconnect means, such as a switch or circuit breaker on the electrical panel, must be provided on the product’s fixed power • Supplier disclaims any liability if: supply leads in accordance with the installation rules. •...
- Page 5 02. CONNECTIONS SCHEME MR-12 (EXAMPLE OF A CONNECTION WITH IMPULSE FROM ANOTHER CONTROL BOARD OR FITTING RECEIVER Example with MC2 This control board is designed to simplify some installations: • Extension of electric lock impulse (from MC2). Motorline Universal Jumper...
- Page 6 Adjust to the desired lock time (maximum 7 seconds). SERR SERR • MR-12 can perform all functions at the same time (img 2, 3, 4 and 5 on the following pages). When the courtesy light output is programmed as bistable, the lock functioning is...
- Page 7 The impulse time given by MC2 for opening the lock may not be enough for certain types of The light will turn on when you press the transmitter key or locks. In this way the MR-12 is prepared, when connected to the MC2 (see figure above) to LAMP...
- Page 8 The use of MR-12 enables the connection of 8K2 resistive type safety bands and transforms it into NC contact. The safety band is connected in the MR-12's 8K2 input and the MR-12's DS output connects with the automatism's control board in the same connections of, for example, the photocells.
